Запчасти Case 6010 (04-02) - HARNESS, MAIN - ELECTRICAL COMPONENTS (55) - ELECTRICAL SYSTEMS

1

341456A1

HARNESS

Main, For Connectors, See figure 4-03

1шт.

2

H437689

HOURMETER

1шт.

3

H437688

FUEL GAUGE

1шт.

4

H437690

CLUSTER

Engine Cluster - Temperature, Oil Pressure, Alternator, Air Filter

1шт.

5

335644A1

CLUSTER

Hydraulic Cluster - E-Stop, Charge Pressure, Oil, Temperature, Filter, Includes: 364672A1, 364673A1

1шт.

364672A1

KIT

Hardware

1шт.

364673A1

KIT

Lamp

1шт.

6

282775A1

IGNITION SWITCH

With Padded Keys, Set Of Two, Includes: 1964831C2

1шт.

1964831C2

IGNITION KEY

Padded

1шт.

7

293797A1

RESTRICTION SWITCH

Air Filter

1шт.

8

D136898

SWITCH

Loader Out Proximity, Drill Head Proximity, Includes: N14113

2шт.

N14113

NUT

Proximity Switch

1шт.

B50458

sealant

1шт.

9

TX401150

SWITCH

Charge Pressure

1шт.

10

H81935

SENDER UNIT

SENDER , Hydraulic Oil Temperature

1шт.

11

360930A1

SWITCH

Beacon and Work Lamps, Drill Fluid On/Off

4шт.

12

359250A1

SWITCH

E-Stop (Emergency Stop), Includes: 359246A1 - 359249A1

2шт.

359246A1

BUTTON

E-Stop (Emergency Stop)

1шт.

359247A1

SWITCH

Normally Open Section

1шт.

359248A1

SWITCH

Normally Closed Section

1шт.

359249A1

HARNESS

E-Stop (Emergency Stop) Switch

1шт.

13

1345488C3

TEMPERATURE SWITCH

Coolant Temperature Switch

1шт.

14

194291A1

TEE

Special

1шт.

15

H139634

SWITCH

Hourmeter Pressure

1шт.

16

368642A1

SWITCH

Engine Oil Pressure

1шт.

17

D128310

RELAY

30A, Loader Interlock, Thrust/Pullback Bypass, Timer Control, Seat Switch, Engine Shutdown

5шт.

18

L71879

DIODE ELEMENT,400V, 3A

1шт.

19

R52278

SWITCH

Master Disconnect

1шт.

20

H35048

IGNITION SWITCH

Glow Plug Heater

1шт.

21

360931A1

SWITCH

Drill Pipe Loader Motor and Cylinder

2шт.

22

283779A1

POWER SOCKET,12V

Auxiliary

2шт.

23

283781A1

CAP,Polyester Elastomer

2шт.

24

235435C1

Fuse

1шт.

25

370434A1

SWITCH

Seat

1шт.

26

360931A1

SWITCH

Horn, Front, If Used

1шт.

27

360931A1

SWITCH

Horn, Rear, If Used

1шт.

366009A1

CABLE

1шт.

R40778

CONDUIT

22 inch, Cut From R44806

1шт.

303884A1

BREAKER

15A, Auxiliary Power , CIRCUIT BREAKERS AND FUSES

1шт.

A59704

BREAKER

80A, Glow Plug , CIRCUIT BREAKERS AND FUSES

1шт.

A149800

FUSE,10 Amp

10A, CIRCUIT BREAKERS AND FUSES

2шт.

A149801

FUSE,Lt Blue, 15 Amp

15A, CIRCUIT BREAKERS AND FUSES

1шт.

A149802

FUSE

20A, CIRCUIT BREAKERS AND FUSES

1шт.
