Запчасти Case 6010 (02-17) - CRANKSHAFT, KUBOTA V2003TE ENGINE (10) - ENGINE

126512A1

CAMSHAFT

Consists Of 1 - 3

1шт.

1

NSS

NOT SOLD SEPARAT

Crankshaft

1шт.

2

125410A1

BALL

4шт.

3

126513A1

SLEEVE

1шт.

4

126514A1

GEAR

1шт.

5

126492A1

KEY

1шт.

6

202246A1

OIL SCRAPER RING

1шт.

7

126875A1

COLLAR

1шт.

8

126876A1

O-RING

1шт.

9

126877A1

NUT

1шт.

10

126878A1

OIL SEAL

1шт.

11

126879A1

CRANKSHAFT BEARING

Standard

1шт.

11

126880A1

CRANKSHAFT BEARING

Undersize 0,20 mm

1шт.

11

202252A1

BEARING LINER

Undersize 0,40 mm

1шт.

12

126882A1

CRANKSHAFT BEARING

Standard

4шт.

12

202254A1

BEARING LINER

Undersize 0,20 mm

4шт.

12

202255A1

CRANKSHAFT BEARING

Undersize 0,40 mm

4шт.

13

125431A1

THRUST BEARING

standard, Standard

2шт.

13

202256A1

BEARING ASSY

Oversize 0,20 mm

2шт.

13

202257A1

BEARING ASSY

Oversize 0,40 mm

2шт.

14

125434A1

THRUST BEARING

standard, Standard

2шт.

14

125435A1

THRUST BEARING

0,20 mm oversize, Oversize 0,20 mm

2шт.

14

125437A1

THRUST BEARING

0,40 mm oversize, Oversize 0,40 mm

2шт.
