Запчасти Case 6010 (09-08) - WRENCHES, FIXED AND ROTATING (89) - TOOLS

1

349370A1

JAW

Upper

2шт.

2

349419A1

PLATE

4шт.

3

413-616

BOLT,Hex, 3/8" - 16 x 1", Gr 5

12шт.

4

492-11038

LOCK WASHER,3/8"

16шт.

5

413-620

BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5

4шт.

6

334441A1

BUSHING

8шт.

7

349472A1

JAW

Upper

2шт.

8

349369A1

INSERT

3-7/8 in, Upper

4шт.

9

349367A1

JAW

Lower

2шт.

10

73050043

INSERT

2-1/2, Lower

4шт.

11

349391A1

JAW

Lower

2шт.

12

439-51672

HEADED PIN,25.4mm OD x 114.3mm L

1 x 4-1/2 in

2шт.

13

432-1624

COTTER PIN,1/4" x 1 1/2"

2шт.

14

349418A2

PIN

2шт.

15

413-816

BOLT,Hex, 1/2" - 13 x 1", Gr 5

4шт.

16

349410A3

BRACKET

Fixed Wrench, Replaces: 349410A2

1шт.

17

426-828

BOLT,Hex, 1/2" - 13 x 1-3/4", Gr 8

4шт.

18

496-21053

WASHER,17/32" x 1 1/16" x .134"

Hardened

4шт.

19

232-4118

NUT,1/2"-13, GC

4шт.

20

331303A2

RING

No Longer Available, Order: 20A

1шт.

20a

331303A3

RING

With Grease Groove

1шт.

21

413-820

BOLT,Hex, 1/2" - 13 x 1-1/4", Gr 5

7шт.

22

391532A1

SHIM

0,127 mm (0,005 in)

1шт.

23

391533A1

SHIM

0,254 mm (0,010 in)

1шт.

24

349415A2

BRACKET

Rotating Wrench, No Longer Available, Order: 24A

1шт.

24a

389878A1

BRACKET

Rotating Wrench, With Holes for Grease Fittings

1шт.

25

219-1

LUBE NIPPLE,1/8" - 27 NPTF

2шт.

26

334442A1

BUSHING

1 in ID

2шт.

27

00647800

FLANGED BEARING,60mm ID x 149.7mm OD x 69.1mm

1шт.

28

322013A1

TUBE,20.93 mm ID, 76.2 mm Length

2шт.

29

321995A1

PLATE

1шт.

30

231-41412

NUT,3/4"-10, GB

3/4

2шт.

31

413-848

BOLT,Hex, 1/2" - 13 x 3", Gr 5

1шт.

32

425-148

JAM NUT,Jam, 1/2"-13, G5

2шт.
