Запчасти Case DH7 (28) - ALTERNATOR INSTALLATION (55) - ELECTRICAL SYSTEMS

1

K956446

ALTERNATOR

ASSEMBLY - (See Figure 30)

1шт.

2

K942129

FAN

- Alternator

1шт.

3

K952702

PULLEY

- Alternator

1шт.

4

K947548

DECAL

- Alternator Instructions

1шт.

5

K950496

FAN

GUARD - Alternator Fan

1шт.

6

K600359

BOLT

- NC (5/16 x 1 1/4)

1шт.

7

K600365

BOLT

- NC (5/16 x 1 1/2)

1шт.

8

K19481

SPRING WASHER

WASHER - Lock (5/16)

2шт.

9

9635082

NUT,5/16" - 18, Gr 5

- NC (5/16)

2шт.

10

K947375

SUPPORT

BRACKET - Support - Alternator

1шт.

11

K608235

STUD

- NC (3/8 x 1) Bracket to Cylinder Block

1шт.

12

88206

BOLT,Hex, 3/8" - 16 x 1", Gr 5

Bracket to cylinder Block Hex, 3/8"-16 x 1", G5, Full Thd

1шт.

13

K19482

SPRING WASHER

WASHER - Lock (3/8) Bracket to Cylinder Block

2шт.

14

280136

NUT,3/8"-16, G8

Bracket to Cylinder Block 3/8"-16, G8

1шт.

15

K951676

STRAP

- Alternator Adjusting

1шт.

16

K650342

BOLT

SCREW

1шт.

17

K626916

WASHER

- Special (5/16)

1шт.

18

K19481

SPRING WASHER

WASHER - Lock (5/16)

1шт.

19

K627028

BUSHING

SPACER - Adjusting Strap

1шт.
