Запчасти Case DH7 (26) - STARTER MOTOR INSTALLATION, HOURMETER DRIVE (55) - ELECTRICAL SYSTEMS

1

K919752

STARTING MOTOR

STARTER MOTOR ASSEMBLY

1шт.

K963825

SOLENOID

- Starter

1шт.

2

413-618

BOLT,Hex, 3/8" - 16 x 1-1/8", Gr 5

SCREW - NC Set (3/8 x 1 1/8)

3шт.

3

K19482

SPRING WASHER

WASHER - Lock (3/8)

4шт.

4

K918762

CABLE

-, Serial Range: Starter-Ground

1шт.

7

K9282553

CONNECTOR - Engine Hourmeter Drive

1шт.

8

K16351

O-RING,3.53mm Thk x 24.99mm ID

SEAL - O-Ring - Engine Hourmeter Drive

2шт.

9

425-147

JAM NUT,Jam, 7/16"-14, G5

- NC (7/16 - Lock) Hourmeter Drive

1шт.

10

K19483

SPRING WASHER

- Lock - Hourmeter Drive

1шт.
