Запчасти Case DH4B (1-18) - RADIATOR INSTALLATION (10) - ENGINE

1

H423400

RADIATOR

1шт.

2

H340588

BUSHING

MOUNT - Rubber

2шт.

3

H182691

RETAINER

WASHER - Mount

2шт.

4

230-4216

LOCK NUT,3/8"-16, GA

NUT - NC Hex (3/8 Lock)

2шт.

5

H373415

SUPPORT

- Radiator

1шт.

6

113-103

BOLT,Hex, 5/16" - 18 x 1", Gr 5

2шт.

7

195-521

WASHER,5/16", SAE

- Flat (5/16)

4шт.

8

131-176

LOCK NUT,Prev Torque, Hex, 5/16" - 18, Gr A

NUT - NC Hex (5/16 Lock)

2шт.

9

H395376

FOAM

- Radiator, Side & Bottom (1700 mm long)

1шт.

10

H395368

FOAM

- Radiator, Top (760 mm long)

1шт.

11

H416255

SHROUD

- Radiator

1шт.

12

H409300

BRACKET

- Support (Top)

1шт.

13

113-207

BOLT,Hex, 3/8" - 16 x 1", Gr 5

1шт.

14

131-52

NUT,3/8"-16, GC

NUT - NC Hex (3/8 Lock)

1шт.

15

H409912

RADIATOR HOSE,33.00 mm ID, 42.00 mm ID x 82.00 mm, SAE 20R4

Upper 33.00 mm ID, 42.00 mm ID x 82.00 mm, SAE 20R4

1шт.

16

214-256

HOSE CLAMP,#20, 0.81" - 1.75", Type F Worm

CLAMP - Hose

4шт.

17

H409920

RADIATOR HOSE,33.00 mm ID, 42.00 mm ID x 120.00 mm, SAE 20R4

Lower 33.00 mm ID, 42.00 mm ID x 120.00 mm, SAE 20R4

1шт.

18

H407353

BUSHING

- Hose

2шт.

19

H416222

INTAKE AIR HOSE,58.80 mm ID, 60.00 mm ID x 150.00 mm, SAE J200 CA 710

HOSE - Air Cleaner

1шт.

20

214-260

HOSE CLAMP,#36, 1.81" - 2.75", Type F Worm

2шт.

D55203

CLEANER ASSY.

AIR CLEANER ASSEMBLY, Includes: Ref. 21

1шт.

21

D48198

AIR CLEANER

ELEMENT - Air Cleaner

1шт.

22

R29938

BALL KNOB

BAND - Mounting

2шт.

23

D67721

SWITCH

INDICATOR - Air Cleaner

1шт.

24

221-355

BALL

COUPLING - Pipe (1/8)

1шт.

25

113-102

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

Hex, 5/16"-18 x 3/4", G5, Full Thd

4шт.

26

131-176

LOCK NUT,Prev Torque, Hex, 5/16" - 18, Gr A

NUT - NC Hex (5/16 Lock)

4шт.

27

H416131

MUFFLER

1шт.

28

H421180

NO LONGER SERVICED

FAN - Engine

1шт.

192-20

LOCK WASHER,Helical Spring, 0.318" ID, CST, ZND

WASHER, LOCK, 5/16"

4шт.

814-8035

BOLT,Hex, M8 x 1.25 x 35mm, Cl 8.8

4шт.

This is the Leland eng. H642223 and the ass'y. is no longer furnished.

1шт.

P/N H427179 Muffler Guard.

1шт.
