Запчасти Case P60 (037A) - ALTERNATOR MOUNTING, DEUTZ DIESEL ENGINE SERIAL NUMBER 1232821 AND AFTER (10) - ENGINE

1

H433180

ALTERNATOR

ASSEMBLY - Deutz engine, parts list figure 39A

1шт.

2

H62521

LINK

- alternator adjusting

1шт.

3

113-103

BOLT,Hex, 5/16" - 18 x 1", Gr 5

1шт.

4

195-521

WASHER,5/16", SAE

- flat, 5/16"

1шт.

5

195-103

WASHER,5/16"

- flat, 5/16"

1шт.

6

131-176

LOCK NUT,Prev Torque, Hex, 5/16" - 18, Gr A

NUT - hex, self-locking, 5/16" - 18 NC

1шт.

7

113-102

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

Hex, 5/16"-18 x 3/4", G5, Full Thd

1шт.

8

192-20

LOCK WASHER,Helical Spring, 0.318" ID, CST, ZND

WASHER, LOCK, 5/16"

1шт.

9

113-442

PREV TORQUE BOLT,Locking, 1/2"-13 x 2 1/4", G5

BOLT - hex head, 1/2" - 13 NC x 2-1/2"

1шт.

10

131-1182

LOCK NUT,1/2"-13, GA

NUT - hex, self-locking, 1/2" - 13 NC

1шт.

11

H671164

BRACKET

- alternator mounting, part of pump mounting bracket, see figure 63A

1шт.

12

H640698

BRACKET

- alternator mounting

1шт.

13

113-103

BOLT,Hex, 5/16" - 18 x 1", Gr 5

2шт.

14

195-521

WASHER,5/16", SAE

- flat, 5/16"

2-4шт.

15

131-176

LOCK NUT,Prev Torque, Hex, 5/16" - 18, Gr A

NUT - hex, self-locking, 5/16" - 18 NC

2шт.

16

H107557

V-BELT,0.38" W

Alternator Drive 0.38" W

1шт.
