Запчасти Case P60 (023A) - ENGINE MOUNTING, DEUTZ DIESEL ENGINE SERIAL NUMBER 1232821 AND AFTER (10) - ENGINE

1

H670711

DEUTZ PART

ENGINE - Deutz F2L 511 diesel, see Parts Catalog No. 2973774 for additional breakdown, not shown

1шт.

2

H432583

MOUNTING PARTS

BRACKET - engine mounting, blower end

1шт.

3

814-14040

BOLT,Hex, M14 x 2 x 40mm, Cl 8.8, Full Thd

- hex head, 14 mm - 2 x 40 mm (8.8)

2шт.

4

892-1108

LOCK WASHER,M8

WASHER - lock, 14 mm

2шт.

5

H432575

MOUNTING PARTS

BRACKET - engine mounting, flywheel end

1шт.

6

814-12035

BOLT,Hex, M12 x 1.75 x 35mm, Cl 8.8, Full Thd

- hex head, 12 mm - 1.75 x 35 mm (8.8)

2шт.

7

892-1112

LOCK WASHER,M12

WASHER - lock, 12 mm

3шт.

8

864-12040

HEX SOC SCREW,M12 x 40mm, Cl 8.8

BOLT - hex head, 12 mm - 1.75 x 40 mm (8.8)

1шт.

9

113-412

BOLT,Hex, 1/2" - 13 x 1-3/4", Gr 5

4шт.

10

H227009

SHIM,.035" Thk

Engine mounting .035" Thk

1шт.

11

H274894

WASHER

- special, 1/2"

8шт.

12

131-1182

LOCK NUT,1/2"-13, GA

NUT - hex self-locking, 1/2" - 13 NC

4шт.

13

H670919

GUARD

- belt

1шт.

14

113-4

BOLT,Hex, 1/4" - 20 x 1", Gr 5

2шт.

15

131-1180

LOCK NUT,1/4"-20, GA

NUT, LOCK, 1/4"-20, GA

3шт.

16

814-8020

BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8, Full Thd

1шт.

17

892-1108

LOCK WASHER,M8

1шт.
