Артикул
Название
Примечание
Количество
1
H151399
FILTER STRAINER
SCREEN - suction filter, tank
1шт.
2
218-1046
ELBOW,90 Degree, 1 1/16"-12, 37 Degree x 1"-11 1/2, NPTF
- 90 degree, 1" NPT, at screen
1шт.
3
H598573
TUBE,0.75" OD x 16.25, 2" L
- suction, tank to hose
1шт.
4
H265413
HOSE ASSY.
HOSE - suction, 26" (660 mm) long
1шт.
5
218-5145
ELBOW,45 Degree Elbow, 7/8" - 14 Male JIC x 3/4" - 16 Male ORB
- 45 degree, adjustable, Includes: Ref. 6
1шт.
7
H575886
PUMP
ASSEMBLY - steering and equipment, .562" (14.3 mm) diameter shaft, parts list figure 178
1шт.
8
218-5280
ELBOW,90 Degree, 3/4"-16, 37 Degree x 9/16"-18, O-Ring
- 90 degree, adjustable, Includes: Ref. 9
1шт.
9
218-5005
O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro
6-1, 90 Duro, .468" ID x .078" Thk, elbow
1шт.
10
H569889
TUBE,0.5" OD
- pressure, pump to hose
1шт.
11
H195370
HOSE
- pressure, tube to tube, 9" (229 mm) long, if used
1шт.
12
H240671
HYDRAULIC HOSE,9.52 mm ID x 508.70 mm, SAE 100R1
Pressure, Pump to Tube, Used in Place of Refs. 8 to 11 on Some Models, If Used, Includes: Ref. 13 9.52 mm ID x 508.70 mm, SAE 100R1
1шт.
13
218-5005
O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro
6-1, 90 Duro, .468" ID x .078" Thk, hose
1шт.
14
H559971
TUBE,0.5" OD x 15.25, 9.625" L
- pressure, hose to valve
1шт.
15
218-5059
HYD CONNECTOR,3/4"-16, 37 Degree x 3/4"-16, O-Ring
CONNECTER, HYD., , Adapter, Straight 3/4"-16, 37º x 3/4"-16, O-Ring
1шт.
17
H550079
LOCK VALVE
VALVE ASSEMBLY - steering and equipment, parts list figure 52
1шт.
18
218-5066
HYD CONNECTOR,7/8" - 14 Male JIC x 3/4" - 16 Male ORB
CONNECTOR, HYD., , straight, Incl. Ref. 19 7/8"-14, 37º x 3/4"-16, O-Ring
1шт.
20
H211284
HYDRAULIC HOSE,12.70 mm ID x 939.80 mm, SAE 100R1
Return, Valve to Reservoir, Used on SN 3751 to 3761 12.70 mm ID x 939.80 mm, SAE 100R1
1шт.
21
218-615
TEE,7/8"-14, 37 Degree x 1/2"-14, NPTF Run
- male, used on SN 3751 to 3761
1шт.
22
221-93
REDUCER,Hex, 3/4" x 1/2" NPT
BUSHING - pipe, reducing, used on SN 3751 to 3761
1шт.
23
H171777
HOSE
- return, 37" (970 mm) long, cooler to reservoir, used on SN, Serial Range: 3751-3761
1шт.
24
218-5230
ELBOW,90 Degree, 3/4"-16, 37 Degree x 3/4"-16, 37 Degree Fem Sw
- 90 degree, swivel, used on SN 3751 to 3761
1шт.
25
H559609
COOLER, OIL
OIL COOLER - hydraulic, used on SN, Serial Range: 3751-3761
1шт.
26
218-5225
ELBOW,90 Degree, 1 1/16"-12, 37 Degree x 3/4"-16, 37 Degree Fem Sw
- 90 degree, swivel, used on SN 3751 to 3761
1шт.
27
H244418
HOSE ASSY.
HOSE - return, 38" (966 mm) long, motor drain to oil cooler, used on SN, Serial Range: 3751-3761
1шт.
See figure 92 for motor drain circuit.
1шт.
28
218-777
PLUG,1 1/16"-12, 37 Degree
- tube, use in exisiting tube from propulsion motor drain, used on SN 3751 to 3761
1шт.
29
H211284
HYDRAULIC HOSE,12.70 mm ID x 939.80 mm, SAE 100R1
Return, Valve to Oil Cooler, Used on SN 3761 to 1140302 12.70 mm ID x 939.80 mm, SAE 100R1
1шт.
30
218-5378
ELBOW,90 Degree, 7/8"-14, 37 Degree x 3/4"-16, 37 Degree Fem Sw
- 90 degree, swivel, used on SN 3761 to 1140302
1шт.
31
H559609
COOLER, OIL
OIL COOLER - hydraulic, used on SN, Serial Range: 3761-1140302
1шт.
32
218-5230
ELBOW,90 Degree, 3/4"-16, 37 Degree x 3/4"-16, 37 Degree Fem Sw
- 90 degree, swivel, used on SN 3761 to 1140302
1шт.
33
H171777
HOSE
- return, 37" (940 mm) long, oil cooler to tee, used on SN, Serial Range: 3761-1140302
1шт.
34
218-615
TEE,7/8"-14, 37 Degree x 1/2"-14, NPTF Run
- male, used on SN 3761 to 1140302
1шт.
35
218-756
CAP,37 Degree, 7/8"-14
Tee, Used on S/N 3761 to 1140302 37º, 7/8"-14
1шт.
36
221-93
REDUCER,Hex, 3/4" x 1/2" NPT
BUSHING - pipe, reducing, used on SN 3761 to 1140302
1шт.
6
218-5006
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
8-1, 90 Duro, .644" ID x .087" Thk, elbow
1шт.
16
218-5006
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
8-1, 90 Duro, .644" ID x .087" Thk, adapter
1шт.
19
218-5006
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
8-1, 90 Duro, .644" ID x .087" Thk, adapter
1шт.
Выбрано товаров: 37
