Запчасти Case 860 (6-65C) - FRONT & REAR AXLE ASSEMBLIES - DIFFERENTIAL LOCK, AXLES W/HYDRAULIC LOCKING DIFFERENTIAL (06) - POWER TRAIN

Схема запчастей Case 860 - (6-65C) - FRONT & REAR AXLE ASSEMBLIES - DIFFERENTIAL LOCK, AXLES W/HYDRAULIC LOCKING DIFFERENTIAL (06) - POWER TRAIN
10
7
3
1
7
2
9
6
4
12
11
8
6
5
8
13

Артикул

Название

Примечание

Количество

111400A1

AXLE

ASSEMBLY - front, with hydraulic locking differential, Includes: Ref. 1 - 23 figure 6-65A, 1 - 13 this figure, 1 - 27 figure 6-65E, 1 - 12 figure 6-65G, 1 - 18 figure 6-65I, 1 - 7 figure 6-65K, and 1 - 27 figure 6-66

1шт.

111401A1

AXLE

ASSEMBLY - rear, with hydraulic locking differential, Includes: Ref. 1 - 23 figure 6-65A, 1 - 13 this figure, 1 - 27 figure 6-65E, 1 - 12 figure 6-65G, 1 - 18 figure 6-65I, 1 - 7 figure 6-65K, and 1 - 27 figure 6-66

1шт.

1

614-8020

BOLT,Hex, M8 x 1.25 x 20mm

- hex, full threads, 8 - 1.25 x 20 mm

2шт.

2

128379A1

SUPPORT

HEAD - cylinder, differential lock

1шт.

3

128376A1

O-RING

- cylinder head

1шт.

4

128373A1

PISTON

- differential lock cylinder

1шт.

5

1966908C1

O-RING

- piston

1шт.

6

932204R1

LOCK PIN,M3 x 20, Slotted

PIN - cotter, 3 x 20 mm

2шт.

7

128366A1

RING, LOCKING

RING - lock, shaft

2шт.

8

128367A1

SPRING

- differential lock

2шт.

9

128381A1

FORK

- differential lock

1шт.

10

128368A1

BUSHING

SLEEVE - differential lock shaft

1шт.

11

144597A1

DRIVE SHAFT

SHAFT - differential lock shaft

1шт.

12

128369A1

FLANGE

- differential lock shaft

1шт.

13

614-8020

BOLT,Hex, M8 x 1.25 x 20mm

- hex, full threads, 8 - 1.25 x 20 mm

2шт.

Выбрано товаров: 15
