Запчасти Case 760 (08-050) - BACKHOE DIPPER CYLINDER HYDRAULIC CIRCUIT (35) - HYDRAULIC SYSTEMS

1

H672270

VALVE

ASSEMBLY, backhoe control, 6 spool, parts list Figs. 8-54 -8-64 (Kontak) and Figs. 8-65A - 8-65K (Commercial Intertech)

1шт.

2

218-5062

HYD CONNECTOR,7/8"-14, 37 Degree x 7/8"-14, O-Ring

straight, 7/8-14 inch flare x O-ring boss, Includes: Ref. 3

1шт.

3

237-6010

O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro

1шт.

4

H672388

TUBE ASSY.,15.88 mm OD

contol valve to dipper cylinder closed end hose

1шт.

5

H433856

HOSE ASSY.

51-3/16 inch (1300 mm) long, dipper cylinder closed end tube to control valve tube

1шт.

6

H672351

TUBE ASSY.,15.88 mm OD

dipper cylinder, rod end

1шт.

7

218-5062

HYD CONNECTOR,7/8"-14, 37 Degree x 7/8"-14, O-Ring

straight, 7/8-14 inch flare x O-ring boss, Includes: Ref. 8

1шт.

8

237-6010

O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro

1шт.

9

H672569

CYLINDER

ASSEMBLY, 4 (102) ID x 17-3/8 inch (441 mm) stroke, backhoe dipper, parts list Fig. 8-72, no longer available, order Ref. 32, 138234A1

1шт.

10

218-5107

90 ELBOW,90 Degree Elbow, 7/8" - 14 Male JIC x 7/8" - 14 Male ORB

Adj. O-ring boss, Incl. Ref. 11

1шт.

11

237-6010

O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro

1шт.

12

H672350

TUBE ASSY.,15.88 mm OD

dipper cylinder, closed end

1шт.

13

214-1456

HOSE CLAMP,#56, 3.06" - 4", Type F Worm

adj, 3-1/16-4 inch dia.

1шт.

14

D38648

BLOCK

SPACER rubber

2шт.

15

H433856

HOSE ASSY.

51-3/16 inch (1300 mm) long, control valve tube to dipper cylinder rod end tube

1шт.

16

H231894

CLAMP

hoses

4шт.

17

413-536

BOLT,Hex, 5/16" - 18 x 2-1/4", Gr 5

4шт.

18

H426775

WASHER

flat, special, hardened

4шт.

19

230-4215

NUT,5/16"-18, GA

4шт.

20

H433518

CLAMP

hoses

1шт.

21

413-640

BOLT,Hex, 3/8" - 16 x 2-1/2", Gr 5

1шт.

22

496-21041

WASHER,13/32" x 13/16" x .089", HDN

1шт.

23

230-4216

LOCK NUT,3/8"-16, GA

1шт.

24

H233304

CLAMP

hoses

4шт.

25

413-552

BOLT,Hex, 5/16" - 18 x 3-1/4", Gr 5

hex, 5/16 NC x 3-1/4 inch

4шт.

26

H426775

WASHER

flat, special, hardened

8шт.

27

230-4215

NUT,5/16"-18, GA

4шт.

28

H672387

TUBE ASSY.,15.88 mm OD

backhoe control valve to dipper cylinder rod end hose

1шт.

29

218-5062

HYD CONNECTOR,7/8"-14, 37 Degree x 7/8"-14, O-Ring

straight, 7/8-14 inch flare x O-ring boss, Includes: Ref. 30

1шт.

30

237-6010

O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro

1шт.

31

D131814

SLEEVE

hose protector

2шт.

32

138234A1

CYLINDER

ASSEMBLY, 4 (102) ID x 17-3/8 inch (441 mm) stroke, backhoe dipper, parts list Fig. 8-73A

1шт.
