Запчасти Case 760 (06-030) - HYDRAULIC OIL CHARGE FILLER (14) - MAIN GEARBOX & DRIVE

Схема запчастей Case 760 - (06-030) - HYDRAULIC OIL CHARGE FILLER (14) - MAIN GEARBOX & DRIVE
2
1
7
8
4
10
5
6
9
11
3
12

Артикул

Название

Примечание

Количество

D131330

FILTER, ENGINE OIL

FILTER, OIL ASSEMBLY, hydraulic, charge, Includes: Ref. 1 - 12

1шт.

1

NSS

NOT SOLD SEPARAT

HEAD filter

1шт.

N13268

PRESSURE SWITCH

ASSEMBLY, restriction, electrical, Includes: Ref. 2 - 7

1шт.

2

NSS

NOT SOLD SEPARAT

WASHER identification, green color

1шт.

3

129-667

NUT,#10-32, LH

2шт.

4

493-21020

LOCK WASHER,Int Tooth, #10

(3/16")

1шт.

6

238-5011

O-RING,0.07" Thk x 0.301" ID, -11, Cl 5, 75 Duro

1шт.

7

NSS

NOT SOLD SEPARAT

RING backup, O-ring

1шт.

8

NSS

NOT SOLD SEPARAT

RING backup, O-ring

1шт.

D126922

FILTER, ELEMENT

ELEMENT, FILTER ASSEMBLY, filter, Includes: Ref. 9 and 10

1шт.

9

NSS

NOT SOLD SEPARAT

ELEMENT filter

1шт.

10

238-5230

O-RING,0.139" Thk x 2.484" ID, -230, Cl 5, 75 Duro

1шт.

11

76349

PLUG,9/16" - 18 ORB

Incl. Ref. 12

1шт.

5

237-6006

O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro

1шт.

12

237-6006

O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro

1шт.

Выбрано товаров: 15
