Запчасти Case 660 (9-124) - BACKHOE, PLOW, REEL CARRIER, AND QUAD DECALS (09) - CHASSIS/ATTACHMENTS

1

321-7038

DECAL

- backhoe control pattern

1шт.

2

H386334

FLOOR MAT

STRIP - anti-skid, backhoe foot rests

2шт.

3

D55216

PAD,2" x 9"

PAD - anti-skid, foor guards

2шт.

4

H434268

DECAL

- engine shut-off

1шт.

5

321-3905

DECAL

- Warning, operate this unit from operator's seat only

1шт.

6

H439359

DECAL

- swing lock

1шт.

7

321-4481

DECAL

- Warning, keep clear of this area, swinging boom can crush

2шт.

8

321-6046

WARNING DECAL

DECAL, WARNING, If you use the backhoe to lift a load that is too heavy

1шт.

9

321-7037

DECAL

- Warning, incorrect operation of this backhoe can result in injury or death

1шт.

9a

104363A1

DECAL

- D125, model number, brown

2шт.

9a

179265A1

DECAL

- D125, model number, gray

2шт.

10

H434977

DECAL

- plow control pattern, lift/swing/blade, used with H674318 plow control valve, reel carrier

1шт.

10a

131939A1

DECAL

- Important, plow lift lever must remain in float position, used with 130806A1 plow control valve, reel carrier

1шт.

11

H435035

DECAL

- plowing, brown letters, reel carrier

1шт.

11

178943A1

DECAL

- plowing, black letters, reel carrier

1шт.

12

H438398

DECAL

- Important, reel carrier lift rating, 1500 lb, brown with white letters, plow

3шт.

12

190335A1

DECAL

- Important, reel carrier lift rating, 1500 lb, black with white letters, plow

3шт.

13

H436751

DECAL

- Important, plow lift lever, brown with white letters, reel carrier

1шт.

13

178939A1

DECAL

- Important, plow lift lever, black with white letters, reel carrier

1шт.

14

H435572

DECAL

- select, trencher/plow, brown with white letters, reel carrier

1шт.

14

179080A1

DECAL

- select, trencher/plow, black with white letters, reel carrier

1шт.
