Запчасти Case 360 (2-14A) - ENGINE AND FUEL FILTER MOUNTING - DEUTZ DIESEL ENGINE MODELS, P.I.N. JAF0104257 AND AFTER (02) - ENGINE

1

114408A1

ENGINE ASSEMBLY

ENGINE ASSY Deutz diesel, not shown, see your authorized Case dealer for engine components

1шт.

2

120809A1

SUPPORT

mounting, engine and ground drive pump, left-hand side

1шт.

3

413-836

BOLT,Hex, 1/2" - 13 x 2-1/4", Gr 5

4шт.

4

H274894

WASHER

flat, 17/32 ID x 1-5/64 inch OD, special

4шт.

5

232-4118

NUT,1/2"-13, GC

4шт.

6

814-14040

BOLT,Hex, M14 x 2 x 40mm, Cl 8.8, Full Thd

hex, 14 - 2 x 40 mm

4шт.

7

896-11014

WASHER,15.5mm ID x 28mm OD x 3mm Thk

flat, 14 mm, hardened

4шт.

8

120890A1

BRACKET

mounting, engine, right-hand

1шт.

9

413-832

BOLT,Hex, 1/2" - 13 x 2", Gr 5

2шт.

10

H274894

WASHER

flat, 17/32 ID x 1-5/64 inch OD, special

2шт.

11

232-4118

NUT,1/2"-13, GC

2шт.

12

814-14030

BOLT,Hex, M14 x 2 x 30mm, Cl 8.8, Full Thd

hex, 14 - 2 x 30 mm

4шт.

13

896-11014

WASHER,15.5mm ID x 28mm OD x 3mm Thk

flat, 14 mm, hardened

4шт.

14

123323A1

SCOOP

air sweep

1шт.

15

413-48

BOLT,Hex, 1/4" - 20 x 1/2", Gr 5

2шт.

16

280129

NUT,1/4"-20

hex lock, 1/4 inch NC

2шт.

17

814-8016

BOLT,Hex, M8 x 1.25 x 16mm, Cl 8.8, Full Thd

hex, 8 - 1.25 x 16 mm

1шт.

18

492-11031

LOCK WASHER,5/16"

1шт.

19

814-6016

BOLT,Hex, M6 x 1 x 16mm, Cl 8.8, Full Thd

2шт.

20

492-11025

LOCK WASHER,1/4"

2шт.

21

120885A1

FITTING

90 degree, special, engine to drain hose; Will sub to A2 and this is for S/N JAF0198252 and prior. For S/N JAF0198252 and after, order 239359A1 fitting.

1шт.

22

D89700

HOSE

600 mm long, engine oil drain

1шт.

23

218-754

CAP,37 Degree, 9/16"-18

Hex, drain hose

1шт.

24

H434289

MOUNTING CLIP,7/8”, Insulated, 1/2” Bolt

hose

1шт.

25

413-620

BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5

1шт.

26

196-1

WASHER,13/32" x 13/16" x .089", HDN

flat, 13/32 x 13/16 x 3/32 inch, hardened

1шт.

27

232-4116

NUT,3/8"-16, GC

1шт.

28

121918A1

BRACKET

fuel filter mounting, Serial Range: attaches-engine

1шт.

29

814-10020

BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8, Full Thd

2шт.

30

892-11010

LOCK WASHER,M10

2шт.

31

413-516

BOLT,Hex, 5/16" - 18 x 1", Gr 5

2шт.

32

H426775

WASHER

flat, hardened

2шт.

33

232-4115

LOCK NUT,5/16"-18, GC

2шт.
