Запчасти Case 360 (9-132) - CAST PLOW BLADE AND 4:1 CHUTE - 18 INCH COVER DEPTH, 1 INCH WIDE BLADE (09) - CHASSIS/ATTACHMENTS

H939071

BLADE AND CHUTE ASSEMBLY - plow, cast, 1 inch wide blade and 18 inch cover depth x 3/4 inch chute clearance, machinery item, order from Machinery Price List, Includes: Ref. 1 - 15

1шт.

1

H430173

HALF BLADE

plow, cast, 18 inch cover depth, dimension "A" is 29 inches

1шт.

2

H672910

CHUTE (DOWNWARD)

cable, 3/4 inch clearance

1шт.

3

H672911

DOOR

chute

1шт.

4

H537787

AXLE PIN

clevis, Serial Range: gate-chute

1шт.

5

H434681

PIN, SPLIT (COTTER)

PIN, COTTER hair, gate pin

1шт.

6

H429514

LINK

chute to blade hinge, upper

2шт.

7

H429506

LINK

chute to blade hinge, lower

1шт.

8

426-840

BOLT,Hex, 1/2" - 13 x 2-1/2", Gr 8

2шт.

9

131-1308

JAM NUT,Jam, 1/2"-13

4шт.

10

H429670

PIVOT

chute, upper

1шт.

11

H433152

PIN

lower link to chute and hinge

2шт.

12

A33531

SNAP RING,#75, Ext

pin #75, Ext

2шт.

13

H429530

PIVOT

chute, lower

1шт.

14

413-872

BOLT,Hex, 1/2" - 13 x 4-1/2", Gr 5

hex, 1/2 NC x 4-1/2 inch

2шт.

15

230-4218

LOCK NUT,1/2"-13, GA

hex, self-locking, 1/2 inch NC

2шт.
