Запчасти Case BPGHP335 (09-17) - BPGHP335 HYDRAULIC SYSTEM

Схема запчастей Case BPGHP335 - (09-17) - BPGHP335 HYDRAULIC SYSTEM
11
12
7
35
36
4
38
45
37
16
1
1
13
17
30
10
14
2
9
46
8
19
15
32
1
3
6
33
34
1
2
31
18
5

Артикул

Название

Примечание

Количество

1

218-5103

90 ELBOW,90 Degree Elbow, 7/16" - 20 Male JIC x 7/16" - 20 Male ORB

7/16 fl x adj Or, Includes 237-6004

3шт.

237-6004

O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro

1шт.

2

218-5106

90 ELBOW,90 Degree Elbow, 3/4" - 16 Male JIC x 3/4" - 16 Male ORB

Incl. 237-6008

2шт.

237-6008

O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro

1шт.

3

218-5128

ELBOW,90° Elbow, 9/16" - 18 Male JIC x 3/4" - 16 Male ORB

Incl. 237-6008

1шт.

237-6008

O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro

1шт.

4

218-5275

ELBOW,90 Degree, 1 5/16"-12, 37 Degree x 1 5/8"-12, O-Ring

1-5/16 fl x 1-5/8 Or, Includes 237-6020

1шт.

237-6020

O-RING,0.118" Thk x 1.475" ID, -920, Cl 6, 90 Duro

1шт.

5

218-5108

ELBOW,90 Degree Elbow, 1-1/16" - 12 Male JIC x 1-1/16" - 12 Male ORB

Incl. 237-6012

1шт.

237-6012

O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro

1шт.

6

218-5138

ELBOW,45 Degree Elbow, 1-1/16" - 12 Male JIC x 1-1/16" - 12 Male ORB

1-1/16-12 fl x Or, Includes 237-6012

1шт.

237-6012

O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro

1шт.

7

218-5424

FITTING

1-1/16 Or x 1/2 fem PT, Includes 237-6012

1шт.

237-6012

O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro

1шт.

8

218-5018

FITTING

3/4 Or x 1/2 PT, Includes 237-6008

1шт.

237-6008

O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro

1шт.

9

218-5136

ELBOW,45 Degree Elbow, 3/4" - 16 Male JIC x 3/4" - 16 Male ORB

Incl. 237-6008

1шт.

237-6008

O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro

1шт.

10

218-491

ELBOW,90 Degree Elbow, 7/16" - 20 Male JIC x 1/4" - 18 Male NPTF

1/4 PT x 7/16 fl

1шт.

11

302856A1

ELBOW

Includes 237-6010

1шт.

237-6010

O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro

1шт.

12

218-5065

HYD CONNECTOR,1-1/16" - 12 Male JIC x 7/8" - 14 Male ORB

Includes 237-6010

1шт.

237-6010

O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro

1шт.

13

218-5064

HYD CONNECTOR,1-1/16" - 12 Male JIC x 1-1/16" - 12 Male ORB

Incl. 237-6012

1шт.

237-6012

O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro

1шт.

14

218-5176

ELBOW,45 Degree Elbow, 1-5/16" - 12 Male JIC x 1-5/16" - 12 Female JIC

1-5/16 fl x sw

1шт.

15

218-5245

TEE,1-5/16" - 12 Male JIC x 1-5/16" - 12 Male JIC x 1-5/16" - 12 Male ORB

1-5/16 fl br x fl x Or, Includes 237-6016

1шт.

237-6016

O-RING,0.116" Thk x 1.171" ID, -916, Cl 6, 90 Duro

1шт.

16

218-5039

HYD CONNECTOR,1-5/8" - 12 Male JIC x 1-5/16" - 12 Male ORB

1-5/8 fl x 1-1/16 Or, Includes 237-6012

1шт.

237-6012

O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro

1шт.

17

302857A1

ELBOW

Includes 237-6012

1шт.

237-6012

O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro

1шт.

18

302340A1

KIT

1-5/8, With Hardware

1шт.

19

302341A1

KIT

1-1/16, With Hardware, To Hydraulic System Pressure Gauge

1шт.

30

98335301

HOSE ASSY.

Upper Reservoir To Lower Reservoir

1шт.

31

98335303

HOSE ASSY.

Hydraulic Pump LS Port To Hydraulic Motor A Port

1шт.

32

98335305

HOSE ASSY.

Hydraulic Motor To Hydraulic Reservoir

1шт.

33

98335304

HOSE ASSY.

Needle Valve To Hydraulic Motor A Port

1шт.

34

98335306

HOSE ASSY.

Hydraulic Pump CD Port To Reservoir

1шт.

35

98335309

HOSE ASSY.

Hydraulic Pump Outlet To Solenoid Valve

1шт.

36

98335308

HOSE ASSY.

Hydraulic Filter Outlet To Hydraulic Pump Inlet

1шт.

37

98335302

HOSE ASSY.

Hydraulic Motor B Port To Hydraulic Filter Inlet

1шт.

38

98335307

HOSE ASSY.

Hydraulic Strainer To Hydraulic Motor Inlet

1шт.

45

99810151

VALVE, CONTROL

Motorized Needle Valve, For Mounting, See Page(s) 9-49, Ref 31

1шт.

433-540

CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 2 1/2", Gr 5

5/16 x 2-1/2, Round Head Square Neck

2шт.

496-21034

WASHER,11/32" x 11/16" x 0.89", HDN

2шт.

231-1445

NUT,5/16"-18, GB

2шт.

46

99821112

VALVE, CONTROL

1шт.

Выбрано товаров: 48
