Запчасти Case TX742 (9.00580[03]) - ROPS CANOPY - COMPONENTS - OPTIONAL CODE 749260001 - VERSION (02) (90) - PLATFORM, CAB, BODYWORK AND DECALS

1

87388977

HOSE,1/4" ID x 1750mm L

1шт.

2

87388978

HOSE

1шт.

3

87334192

JOYSTICK

1шт.

5

76095501

MANIPULATOR

ASSY

1шт.

6

10902231

SCREW,Hex, M6 x 16mm, Cl 10.9

4шт.

7

14496431

WASHER,6.4mm ID x 12.5mm OD x 1.6mm Thk

4шт.

9

76092639

45 ELBOW,7/16"-20 x 1/4"-19 Gas

- Assy

2шт.

10

71404163

O-RING,2.4mm Thk x 10.8mm ID, 90 Duro

1шт.
