Запчасти Case 689G (08-04) - HYDRAULIC TANK AND FILTER (08) - HYDRAULICS

1

310152A1

TANK, HYDRAULIC OIL

hydraulic, parts list Figure 8-06

1шт.

2

310448A1

BOLT

hex flange, 3/8 NC x 3/4 inch

3шт.

3

310462A1

FILTER

ASSEMBLY hydraulic oil, Includes: Ref. 3A

1шт.

3a

310029A1

FILTER, ELEMENT

ELEMENT, FILTER

1шт.

4

309951A1

ADAPTER

straight

1шт.

5

309964A1

FITTING

ADAPTER straight

2шт.

6

309953A1

FITTING

ELBOW, 90°

1шт.

7

309963A1

ADAPTER

straight

1шт.
