Запчасти Case 95XT (06-30) - STEEL TRACK (NORTH AMERICA) (06) - POWER TRAIN

365257A1

ASSEMBLY

Used With 12 x 16.5 Inch Tire, Consists Of 1 - 5

2шт.

1

365259A1

PAD

Replaces 244709A1

20шт.

2

365261A1

LINK

Replaces 244714A1

40шт.

3

434-830

CARRIAGE BOLT,Sht Sq Nk, 1/2" - 13 x 1 7/8" , Gr 5

80шт.

4

365260A1

BUSHING

Replaces 244710A1

80шт.

5

231-4138

LOCK NUT,1/2"-13, GB

80шт.

294929A1

SET OF PARTS

Repair Kit, Used With 12 x 16.5 Inch Tire, Consists Of 6 - 10

1шт.

6

365259A1

PAD

Replaces 244709A1

1шт.

7

244714A1

LINK

2шт.

8

434-830

CARRIAGE BOLT,Sht Sq Nk, 1/2" - 13 x 1 7/8" , Gr 5

4шт.

9

244710A1

RING

4шт.

10

231-4138

LOCK NUT,1/2"-13, GB

4шт.

365731A1

ASSEMBLY

Used With 33/15.5 x 16.5 Inch Tire (Galaxy), Consists Of 1 - 5, Replaces 324062A1

2шт.

1

365732A1

PAD

Replaces 324064A1

40шт.

2

365261A1

LINK

Replaces 244714A1

80шт.

3

434-830

CARRIAGE BOLT,Sht Sq Nk, 1/2" - 13 x 1 7/8" , Gr 5

160шт.

4

365260A1

BUSHING

Replaces 244710A1

160шт.

5

231-4138

LOCK NUT,1/2"-13, GB

160шт.
