Артикул
Название
Примечание
Количество
REF
INSTRUCTION
MODELS WITH FLOOR HEATER AND MODELS WITHOUT HEATER
1шт.
1
432310A1
SERVICE KIT
ROPS; Order From WholeGoods; Incl. Decals; Incl. 2 - 11
1шт.
2
321274A1
SEAL
1шт.
3
321268A1
CHANNEL
1шт.
4
321269A1
GLASS
Rear
1шт.
5
333988A1
SEAL
639 mm (25-5/32 in); Lower Rear Window
1шт.
6
321276A1
SEAL
Rear Window Edge
2шт.
7
414792A2
BRACKET
300 mm (11-13/16 in) Between Bolt Holes
1шт.
8
362337A1
KNOB
2шт.
9
321275A1
SEAL
587 mm (23-1/8 in)
1шт.
10
611-8020
CARRIAGE BOLT,M8 x 20mm, Class 4.6
3шт.
11
832-41308
NUT,M8 x 1.25, Cl 10
3шт.
12
419844A1
BAR
Seat
1шт.
13
189609A1
BALL STUD,M8 x 1.25
M8
2шт.
14
825-5148
SERRATED NUT,M8, Flg Ser
2шт.
15
189787A2
SHOCK ABSORBER
1шт.
16
136209A1
BUSHING,12.77mm ID x 19.12mm OD x 25.53mm L
2шт.
17
496-21053
WASHER,17/32" x 1 1/16" x .134"
2шт.
18
D143415
SNAP RING,0.50” ID, Klipring
1/2
2шт.
19
614-10040
BOLT,Hex, M10 x 1.5 x 40mm, Cl 8.8, Full Thd
2шт.
20
829-1410
NUT,M10 x 1.5, Cl 10.9
2шт.
21
254307A1
CLIP
2шт.
22
291259A2
COWL
Hood
1шт.
23
614-8020
BOLT,Hex, M8 x 1.25 x 20mm
6шт.
24
895-15008
WASHER,9mm ID x 20mm OD x 1.6mm Thk
6шт.
25
L18337
CABLE TIE,9.95"-12.1" lg
CABLE STRAP 15 in; Manual, Operators
1шт.
26
293887A1
COVER
70 mm (2-3/4 in); Models Without Lift Hooks; See Figure 09-28
2шт.
27
R46463
SCREW,0.18" x 0.75"
Manual Retention
1-2шт.
28
R46464
CASE
1-2шт.
29
151-522
RIVET,Pop, 3/16" x .575"
3/16 x 7/32
3шт.
30
495-31020
WASHER,#10
(13/64" x 15/32" x 3/64")
3шт.
31
414635A1
COVER,25.4mm OD x 0.51mm Thk
25.4 mm (1 in); Gray
2шт.
32
353-402
PLUG,Dome, .375" hole, Nylon
1-2шт.
33
353-411
PLUG,Dome, 1.000" hole, Nylon
1-3шт.
34
313149A1
SEAL
355 mm (14 in), Screen Frame; North American Only; Screen Frame; Models With Heater; See Figure 09-36
2шт.
35
313150A1
SEAL
774 mm (30-1/2 in); North American Only; Toe Guard; Models With Heater; See Figure 09-36
1шт.
36
225420A1
ANGLE BAR
ROPS to Frame Seal Holder
2шт.
37
315083A1
SEALING STRIP
610 mm (40 inch); Europe Only; Window Frame
1шт.
38
275066A1
SEAL
Hood Extension Panel
1шт.
39
188980A1
SEAL
2шт.
353-400
PLUG,Dome, .250" hole, Nylon
Models with top window; See Figure 09-35
2шт.
Выбрано товаров: 41
