Артикул
Название
Примечание
Количество
1
251058A2
HANDLE
Left Hand, No Longer Available, Order 1A
1шт.
1a
328601A1
HANDLE
Left Hand
1шт.
1a
87597590
LEVER
Left Hand; Replaces 328601A1
1шт.
2
251060A2
HANDLE
Right Hand, No Longer Available, Order 2A
1шт.
2a
328603A1
HANDLE
Right Hand
1шт.
2a
87597591
LEVER
Right Hand; Replaces 328603A1
1шт.
3
257384A1
SPACER
2шт.
4
614-8020
BOLT,Hex, M8 x 1.25 x 20mm
Use Loctite No. 242
2шт.
B17577
LOCTITE
No. 242, 6 ml, Blue
1шт.
5
495-21038
WASHER,5/16"
(flat, 3/8 x 7/8 x 3/32")
2шт.
6
121-227
STEP BOLT,Hex Skt, 3/8" - 16 - 1/2" x 1/2"
2шт.
7
231-5146
FLANGE NUT,3/8"-16
2шт.
8
195366A2
PIN
2шт.
9
282300A3
SUPPORT
Right Hand, Replaces: 282300A1, 282300A2
1шт.
9a
282301A3
SUPPORT
Left Hand, Not Illustrated, Replaces: 282301A1, 282301A2
1шт.
10
827-12070
BOLT,Hex, M12 x 1.75 x 70mm, Cl 10.9
4шт.
11
240669A1
WASHER
6шт.
12
H426395
MOUNTING PARTS
4шт.
13
195-81030
WASHER
17/32 x 1-1/2 x 3/16
6шт.
14
832-41312
NUT,M12 x 1.75, Cl 10
4шт.
15
144345A3
PIVOT PIN,25.4mm OD x 825mm L
1шт.
16
827695C1
CIRCLIP
1 in
2шт.
16a
295076A1
SEAL
Models With Deluxe Heater and Air Conditioning
2шт.
19
832-41310
NUT,M10 x 1.5, Cl 10
1шт.
20
222490A2
GAS STRUT
235 strk, Replaces: 222490A1
1шт.
21
814-10060
BOLT,Hex, M10 x 1.5 x 60mm, Cl 8.8
1шт.
23
832-41310
NUT,M10 x 1.5, Cl 10
1шт.
24
247992A2
GAS STRUT,610mm Extended, 380mm Compressed
Used On Mdels With Side and Top Windows, N.A. Only
1шт.
24
282098A1
GAS STRUT,612.1mm Extended, 377.9mm Compressed
Heavy Duty, Models With Deluxe Heater and Air Conditioning
1шт.
24
247992A2
GAS STRUT,610mm Extended, 380mm Compressed
Standard, Europe Only
1шт.
24
282098A1
GAS STRUT,612.1mm Extended, 377.9mm Compressed
Heavy Duty, Used On Models With Side and Top Windows, Europe Only
1шт.
26
814-10060
BOLT,Hex, M10 x 1.5 x 60mm, Cl 8.8
1шт.
28
832-41310
NUT,M10 x 1.5, Cl 10
2шт.
29
254697A1
SPACER
3шт.
30
254698A1
SPACER
1шт.
18
895-15010
WASHER,11mm ID x 24mm OD x 2mm Thk
4-7шт.
22
895-15010
WASHER,11mm ID x 24mm OD x 2mm Thk
2шт.
27
895-11010
WASHER,11mm ID x 20mm OD x 2mm Thk
1шт.
Выбрано товаров: 40
