Артикул
Название
Примечание
Количество
1
186308A2
SUPPORT
Left Hand
1шт.
2
179492A5
SUPPORT
Right Hand
1шт.
3
275024A1
LEVER
For Attaching Parts, See Page(s) 4-59 - 4-71
2шт.
4
238357A3
PIVOT
2шт.
5
237774A1
SHAFT
2шт.
6
864-6016
HEX SOC SCREW,M6 x 16mm, Cl 8.8
4шт.
7
237772A1
SUPPORT
2шт.
8
112380A1
BEARING ASSY
Incl Ref 9
4шт.
9
465004R91
BEARING ASSY,0.6693" ID x 1.5748" OD x 0.4724"
1шт.
Part of P/N 112380A1
1шт.
10
396-41028
WASHER,.281" x 7/8" x .098", HDN
2шт.
11
845-6016
BOLT,Hex Flg, M6 x 16mm, Cl 8.8
M6 x 16
2шт.
12
845-6020
BOLT,Hvy Hex, M6 x 20mm, Cl 8.8
6шт.
13
825-5146
SERRATED NUT,M6, Flg Ser
6шт.
15
418663A2
LEVER
Replaces: 418663A1
1шт.
16
121-251
STEP BOLT,Hex Skt, 5/16" - 18 - 3/8" x 3/8"
1шт.
17
278332A1
SPRING WASHER
if used
1шт.
18
230-4215
NUT,5/16"-18, GA
1шт.
19
614-10030
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8, Full Thd
8шт.
21
825-51410
FLANGE NUT,M10, Flg Ser
8шт.
22
418585A1
COIL SPRING
1шт.
23
895-15006
WASHER,6.6mm ID x 25mm OD x 1.6mm Thk
2шт.
25
308877A1
PAD
Left Hand Console, Models With Deluxe Heater
1шт.
26
313278A1
BAND
50 mm (2 inch), Lock Slot Cover, Models With Deluxe Heater and Air Conditioning
1шт.
27
308879A1
PAD
Right Hand Console, Models With Deluxe Heater
1шт.
28
313323A1
SEAL
Console, Models With Deluxe Heater
2шт.
20
895-11010
WASHER,11mm ID x 20mm OD x 2mm Thk
8шт.
Выбрано товаров: 29
