Запчасти Case 85XT (09-46) - DECALS (09) - CHASSIS

1

419899A1

DECAL

95XT Model Designation, Not Shown

2шт.

1

419900A1

DECAL

90XT Model Designation, Not Shown

2шт.

1

419901A1

DECAL

85XT Model Designation, Not Shown

2шт.

1

419902A1

DECAL

75XT Model Designation

2шт.

2

315955A1

DECAL

Fuse and Relay

1шт.

3

303878A2

DECAL

Operating Capacity

1шт.

4

256365A2

DECAL

Lock/Unlock

1шт.

5

139879A1

DECAL

Diesel Fuel

1шт.

6

251753A1

DECAL

Hydraulic Fluid

1шт.

7

139728A1

DECAL

Tie Down

4шт.

8

139729A1

DECAL

Lift Hook

1-3шт.

9

294752A1

REFLECTOR,94mm L X 44mm W

Red

2шт.

10

331704A1

DECAL

Lubrication

1шт.

11

329051A1

DECAL

Emergency Exit

1шт.

12

417654A1

DECAL

Case, 3-7/16 x 15-15/16

2шт.

12

87389374

DECAL

Case; Replaces 417654A1

2шт.

13

412276A1

DECAL

Case, 3-3/4 x 18-11/16; High Flow Models; If Used; Not Illustrated

1шт.

13

87389371

DECAL

Case, Logo; Replaces 412276A1

1шт.

14

417661A1

DECAL

Case, With Stripes, LH, 1545mm/60.83" OAL

1шт.

14

417675A1

DECAL

Case, With Stripes, LH, 1749mm/68.7" OAL

1шт.

15

417663A1

DECAL

Case, With Stripes, RH, 1545mm/60.83" OAL

1шт.

15

417677A1

DECAL

Case, With Stripes, RH, 1749mm/68.7" OAL

1шт.

16

430311A1

DECAL

Case, With Stripes; Right Hand; High Flow Models; If Used; Not Illustrated

1шт.

For 75XT Models Only

1шт.
