Артикул
Название
Примечание
Количество
1
305660A1
DOOR
Rear, Without Door Latch, Ref. 30, If Used
1шт.
2
280672A2
DEFLECTOR
1шт.
Used with rear door P/N 434584A1
1шт.
3
844-8020
BOLT,Hvy Hex, M8 x 20mm, Cl 8.8
4шт.
Used with rear door P/N 434584A1
1шт.
4
194152A1
STAPLE
1шт.
5
614-8025
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8, Full Thd
2шт.
7
832-41308
NUT,M8 x 1.25, Cl 10
2шт.
8
194280A1
ROD
1шт.
9
1978473C1
HANDLE
1шт.
10
282510A1
U-BOLT
BOLT "U"
1шт.
11
895-11006
WASHER,6.6mm ID x 12mm OD x 1.6mm Thk
2шт.
12
832-41306
NUT,M6 x 1, Cl 10
2шт.
13
H373779
LARGE PLATE
PLATE, LARGE
1шт.
14
827-16060
BOLT,Hex, M16 x 2 x 60mm, Cl 10.9
2шт.
15
896-11016
WASHER,17.5mm ID x 30mm OD x 4mm Thk
2шт.
16
248461A1
BUSHING,16.5mm ID x 24mm OD x 22mm L
2шт.
17
832-41316
NUT,M16 x 2, Cl 10
2шт.
18
248988A1
THRUST WASHER
1шт.
19
307942A1
INSULATOR
7шт.
Used with rear door P/N 434584A1
1шт.
20
614-5025
BOLT,Hex, M5 x 0.8 x 25mm, Cl 8.8, Full Thd
M5 x 25, if used
14шт.
22
E99641
CAP
Plastic, If Used
14шт.
23
297245A1
CABLE
Door Stop, Includes: H439276, Ref 24
1шт.
24
H439276
PIN,12mm OD x 50mm L
Lock
1шт.
Part of door stop cable P/N 297245A1
1шт.
25
348452A1
FASTENER,Push-In, 37mm L, Nylon
Push-In, 7.14 Hole dia.
14шт.
Used with rear door P/N 434584A1
1шт.
26
348434A1
WASHER,7.14mm ID x 44.5mm OD x 1.3mm Thk
7.14 ID x 44.5 OD
14шт.
Used with rear door P/N 434584A1
1шт.
27
434584A1
DOOR
Rear, With Door Latch, Ref. 30, If Used, Used With Ref. 2, 3, 19, 25, 26, For Mounting, See Ref. 14 - 18
1шт.
28
434565A1
ROD
Latch Pull
1шт.
29
380751A1
NUT
Push
1шт.
30
R55002
LATCH
1шт.
31
814-6035
BOLT,Hex, M6 x 1 x 35mm, Cl 8.8
2шт.
32
895-25006
WASHER,6.6mm ID x 18mm OD x 1.6mm Thk
2шт.
33
832-41406
NUT,M6 x 1, Cl 8
2шт.
6
895-15008
WASHER,9mm ID x 20mm OD x 1.6mm Thk
2шт.
Выбрано товаров: 39
