Артикул
Название
Примечание
Количество
Loader
1шт.
North American Models JAF0318922-
1шт.
European Models JAF0352169-
1шт.
409062A2
VALVE
Loader, Two Spool, Consists Of 1 - 31, Also Includes 08-15
1шт.
87431787
VALVE
Control; Incl. 1 - 31; Replaces 409062A2
1шт.
388170A3
SPOOL
Lift, With Manual Detent, Consists Of 1 - 8, Used With 409062A2
1шт.
87427902
SPOOL
Lift, With Manual Detent; Replaces 388170A3; Incl. 1 - 4, 5A, 6 - 8; Used With 87431787
1шт.
1
NSS
NOT SOLD SEPARAT
Spool, Loader Lift
1шт.
3
G102711
RETAINER COLLAR,19.3 mm ID x 32.97 mm OD
1шт.
4
375708A1
SPRING WASHER
1шт.
5
380571A1
TENSION SPRING
1шт.
6
375707A1
RETAINER
1шт.
5a
1994596C1
SPRING
Centering
1шт.
383471A1
Manual Detent, Not Serviced As An Assembly, Order Components, Consists Of 7 - 8
1шт.
7
383472A1
DETENT
Use Loctite
1шт.
345-601
LOCTITE
No. 203, 1 ml
1шт.
8
237-6003
O-RING,0.064" Thk x 0.301" ID, -903, Cl 6, 90 Duro
1шт.
388173A4
SPOOL
Loader Bucket, Auxiliary, Consists Of 9 - 14, Used With 409062A2
1шт.
87427904
SPOOL
Loader Bucket; Auxiliary; Replaces 388173A3; Incl. 9 - 11, 12A, 13, 14; Used With 87431787
1шт.
9
NSS
NOT SOLD SEPARAT
Spool
1шт.
11
G102711
RETAINER COLLAR,19.3 mm ID x 32.97 mm OD
1шт.
12
380571A1
TENSION SPRING
1шт.
12a
1994596C1
SPRING
Centering
1шт.
13
375708A1
SPRING WASHER
2шт.
14
100-1647
SNAP RING,#47, Ext
1шт.
15
411874A2
SOLENOID
Spool Lock, Includes 16, Used With 409062A2
1шт.
15
87429888
SOLENOID VALVE
Spool Lock; Incl. 16A; Used With 87431787
1шт.
16a
237-8006
O-RING,0.078" Thk x 0.468" ID, -906, Cl 8, 90 Duro
3/8 OD
1шт.
17
411875A2
SOLENOID
Spool Lock, Includes 18, Used With 409062A2
1шт.
17
87429889
SOLENOID VALVE
Spool Lock; Incl. 18A; Used With 87431787
1шт.
18a
237-8006
O-RING,0.078" Thk x 0.468" ID, -906, Cl 8, 90 Duro
3/8 OD
1шт.
20
65457C1
SEAL,19.04mm ID x 25.5mm OD x 3.17mm Thk
2шт.
21
417360A1
BLOCK
Used With 409062A2, 87431787
1шт.
23
409916A1
PLUG
Includes 24
2шт.
24
237-6006
O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro
1шт.
25
399853A1
TENSION SPRING
Detent
2шт.
26
211-1007
BALL,7/32" Dia
Gr 24, CRS
2шт.
27
9625178
PLUG,9/16" - 18 ORB
1шт.
28
G107780
VALVE, CHECK
2шт.
29
375714A2
CAP
Centering Spring, Use Loctite
1шт.
B17423
LOCTITE
Loctite, No. 271, 50 ml
1шт.
30
814-6080
BOLT,Hex, M6 x 1 x 80mm, Cl 8.8
2шт.
31
895-11006
WASHER,6.6mm ID x 12mm OD x 1.6mm Thk
2шт.
16
237-6006
O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro
1шт.
18
237-6006
O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro
1шт.
Выбрано товаров: 49
