1
373664A5
HARNESS
Cab
1шт.
2
L18337
CABLE TIE,9.95"-12.1" lg
CABLE STRAP 15 in.
3шт.
3
375634A4
HARNESS
See Figure 04-10, Models With Cab Options
1шт.
4
398374A2
HARNESS
Front Door Switch; See Figure 04-17; Models With Lexan
1шт.
5
L71879
DIODE ELEMENT,400V, 3A
4шт.
6
398298A2
HARNESS
Front Door; See Figure 04-17; Models With Glass
1шт.
7
396940A1
HARNESS
Models With Deluxe Heater; See Figure 04-16
1шт.
8
389135A1
HARNESS
Models With Foot Heater; See Figure 04-16
1шт.
9
378884A2
STRAP,254mm L
3шт.
10
389971A1
PANEL, INSTRUMENTS
PANEL, INSTRUMENT Left Hand Standard; See Figure 04-26
1шт.
389971A1R
REMAN-INSTR CLUSTER
40XT
1шт.
389971A1C
CORE-CLUSTER, INSTR
Return Number
1шт.
11
189492A3
PANEL, INSTRUMENTS
PANEL, INSTRUMENT Right Hand Standard; See Figure 04-26
1шт.
11
189493A1
PANEL, INSTRUMENTS
PANEL, INSTRUMENT Right Hand Deluxe Models With Automatic Engine Shutdown; See Figure 04-31; Not Illustrated
1шт.
12
222004A2
HEADLIGHT,Halogen, 12V, 50W, Clear
Work; See Figure 04-27
2шт.
13
347610A1
ANCHOR
STRAP
10шт.
14
293828A1
HARNESS
Models With Rotating Beacon; See Figure 04-25
1шт.
15
H439303
CLIP
4-5шт.
16
392269A2
SWITCH
Seat Bar; See Figure 04-15
1шт.
17
302137A2
HARNESS
Seat Switch; See Figure 04-15
1шт.
18
516-2395
CLAMP,J, 7/16" Insul, 3/8" Bolt
9.5 mm
1шт.
19
324882A1
HARNESS
Dome Light
1шт.
20
322783A1
HOLDER
Dome Light Mount
1шт.
21
430975A2
SEAL
Dome Light
1шт.
22
325271A1
COURTESY LIGHT
DOME LIGHT
1шт.
