Артикул
Название
Примечание
Количество
1
H435848
HANDLE
Throttle Control
1шт.
3
433-628
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 3/4", Gr 5
3/8 NC x 1-3/4 in; North American Models
1шт.
3
433-824
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/2", Gr 5
European Models
1шт.
4
1342374C1
DISC
Replaces D139323
1шт.
5
R14771
WASHER
Throttle Lever
1шт.
6
495-11041
WASHER,0.406" ID x 0.812" OD x 0.065" W
(13/32 x 13/16 x 1/16"), North American Models
1шт.
6
895-11010
WASHER,11mm ID x 20mm OD x 2mm Thk
European Models
1шт.
7
425-106
NUT,3/8"-16, Cl 5
North American Models
2шт.
7
825-1410
NUT,M10, Cl 8
European Models
2шт.
8
H169920
BALL JOINT
1/4 inch NF
1шт.
9
H435850
ROD
Throttle
1шт.
10
425-114
NUT,1/4"-28, G5
4шт.
11
H169920
BALL JOINT
1/4 inch NF; North American Models
1шт.
11
A10329
BALL JOINT,1/4" - 28 x 1"
1/4 inch NF; European Models
1шт.
12
492-11025
LOCK WASHER,1/4"
2шт.
13
A154051
COCK, DRAIN
Fuel Shutoff
1шт.
14
214-1404
HOSE CLAMP,#04, 0.25" - 0.62", Type F Worm
4шт.
15
D124109
FUEL HOSE
1200 mm (47-1/4 inch); Fuel Supply; Cut From A21562X Bulk Hose
1шт.
16
217-142
ELBOW,45 Degree Elbow, 3/8" Hose Barb x 1/4" Male NPTF
45 degree, 3/8 stem end x 1/4 inch PT
1шт.
17
L18337
CABLE TIE,9.95"-12.1" lg
CABLE STRAP 15 in
1шт.
18
217-292
FITTING,90 Degree Elbow, 1/4" Hose Barb x 1/8" Male NPTF
1шт.
19
D127925
HOSE,6.35 mm ID x 1420.00 mm, SAE 30R6 or SAE 30R7
Fuel Return; Cut From A21561X Bulk Hose
1шт.
A21561X
HOSE,6.35mm ID x 7620mm L
6 (1/4) x 13 (1/2) x 7620 mm (300 inch)
1шт.
Выбрано товаров: 25
