Запчасти Case 1830 (054) - CARBURETOR LINES AND FUEL PUMP FOR MODELS WITH GEAR DRIVEN GOVERNOR (10) - ENGINE

1

D62784

NUT

hex, 8 mm

1шт.

2

D62766

HHCS, 8 mm x 25 mm

1шт.

3

D62774

WASHER

WASHER lock, 8 mm

2шт.

4

D62708

GASKET

pump

1шт.

4a

D65147

GASKET

spacer

1шт.

5

D65176

SPACER

pump

1шт.

5a

D65178

HHCS metric

1шт.

5b

D62776

WASHER lock

1шт.

5c

D62777

WASHER

WASHER flat

1шт.

D62924

PUMP

ASSEMBLY fuel, included Ref. 6 through 11 and P/N D62738.

1шт.

D62924 fuel pump changed to N7708 fuel pump. Sub # pump has 3 fuel line connections. The return line connection should be plugged. This connection is the one on the side of the fuel pump. Use the cap plug and clamp that comes with the fuel pump kit to block the port.

1шт.

6

NSS

NOT SOLD SEPARAT

COVER pump

1шт.

7

NSS

NOT SOLD SEPARAT

BODY pump

1шт.

D62738

KIT

repair, included Ref. 8 through 11.

1шт.

8

NSS

NOT SOLD SEPARAT

SCREW cap

1шт.

9

NSS

NOT SOLD SEPARAT

WASHER felt

1шт.

10

NSS

NOT SOLD SEPARAT

FILTER fuel

1шт.

11

D62814

GASKET

SEAL cover

1шт.

12

D62659

CLAMP fuel line

2шт.

13

D62722

HOSE fuel

2шт.

14

D62913

HOSE

TUBE fuel, pump to carburetor, 255 mm, 10 inches, long

1шт.

15

D62624

HOSE tube protector, 40 mm, use before engine sn 2707

1шт.

15

D66331

HOSE tube protector, 40 mm, used engine sn 2707 thru 4136

1шт.

16

RESERVED

1шт.

17

D62911

HOSE

Head, Serial Range: Cover-Carburetor

1шт.

18

D62726

TEE

male and female

1шт.

19

D62700

ORIFICE

intake manifold

1шт.

20

D62736

HOSE

Intake, Serial Range: Manifold-Carburetor

1шт.

21

214-253

HOSE CLAMP,#10, 0.56" - 1.06", Type F Worm

CLAMP hose

1шт.

22

D62734

HOSE

at water pump

1шт.

23

214-251

HOSE CLAMP,#06, 0.44" - 0.78", Type F Worm

CLAMP hose

6шт.

24

D62699

TEE

air release

1шт.

25

D62697

SCREW

bleed, air

1шт.

26

D62735

INTAKE AIR HOSE,9.50 mm ID, 12.40 mm ID x 247.00 mm

At Carburetor 9.50 mm ID, 12.40 mm ID x 247.00 mm

1шт.

27

D62912

HOSE

, Serial Range: Carburetor-Manifold

1шт.

28

D62912

HOSE

Cylinder, Serial Range: Head-Carburetor

1шт.

29

214-253

HOSE CLAMP,#10, 0.56" - 1.06", Type F Worm

CLAMP hose

1шт.

30

D65148

HOSE at carburetor, used before engine sn 2707

1шт.

30

D76928

HOSE

at carburetor, used engine sn 2707 thru 4136

1шт.

31

D62930

TUBE

carburetor to distributor, used before engine sn 2707

1шт.

31

D76929

TUBE

carburetor to distributor, used engine sn 2707 thru 4136

1шт.

32

D65149

HOSE at distributor, used before engine sn 2707

1шт.

32

D76928

HOSE

at distributor, used engine sn 2707 thru 4136

1шт.

33

49838

CLAMP

tube sleeve, bracket

1шт.

FILTER KIT FOR NEW PUMP N7708

1шт.
