Запчасти Case 1830 (052) - GOVERNOR LINKAGE AND GOVERNOR BELT DRIVEN (10) - ENGINE

1

D80758

GOVERNOR

GOVERNOR ASSEMBLY

1шт.

THE PULLEY IS PART NUMBER D86580.

1шт.

2

D80857

V-BELT,0.40" W x 48.00" L

Crank to Governor to Fan, Used with Belt Driven Governor 0.40" W x 48.00" L

1шт.

3

D80856

V-BELT,0.38" W x 28.00" L

Alternator to Crank, Use with Belt Driven Governor 0.38" W x 28.00" L

1шт.

4

D80791

BRACKET

mounting, governor

1шт.

REF: #4 ADJUSTING BOLT FOR THIS BRACKET IS P/N 28-420

1шт.

5

D80796

BRACKET

mounting, governor

1шт.

6

13-612

BOLT,Hex, 3/8" - 16 x 3/4", Gr 5, Full Thd

3шт.

7

92-6

LOCK WASHER,3/8"

3шт.

8

25-106

NUT,3/8"-16, G5

hex, 3/8" - 16 NC

3шт.

9

95-6

WASHER,3/8"

flat, 3/8"

3шт.

10

92-6

LOCK WASHER,3/8"

3шт.

11

13-620

BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5, Full Thd

3шт.

12

D80872

ROD

, Serial Range: governor-carburetor

1шт.

13

A10329

BALL JOINT,1/4" - 28 x 1"

JOINT ball

2шт.

14

25-114

NUT,1/4"-28, G5

hex, lock, 1/4" - 28 NF

2шт.

15

92-4

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

1шт.

16

92-4

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

1шт.

17

25-114

NUT,1/4"-28, G5

hex, lock, 1/4" - 28 NF

1шт.

18

D80853

SPACER

manifold

1шт.

19

D80981

STUD

manifold

2шт.

20

95-6

WASHER,3/8"

flat, 5/16"

2шт.

21

D62610

SPACER

WASHER lock, bracket, Serial Range: manifold-head

2шт.

22

D87010

NUT

bracket, Serial Range: manifold-head

2шт.

D19234

KIT

belt driven governor, includes all parts and instructions to convert models with gear driven governor to belt driven governor

1шт.
