Запчасти Case 1818 (6-18) - AXLES AND DRIVE CHAINS, P.I.N. JAF0095593 AND AFTER (06) - POWER TRAIN

118986A1

AXLE ASSEMBLY wheel, front, , Includes: Ref. 1-16, not available for service order component parts separately

2шт.

118987A1

AXLE ASSEMBLY wheel, rear, Includes: Ref. 1-16, not available for service, order component parts separately

2шт.

1

126332A1

AXLE

ASSEMBLY wheel, front, used with 118989A1 axle assembly, Includes: Ref. 3 and 4

1шт.

2

126331A1

AXLE

ASSEMBLY wheel, rear, used with 118987A1 axle assembly, Includes: Ref. 3 and 4

1шт.

3

D91709

WHEEL BOLT

BOLT special, wheel

6шт.

4

NSS

NOT SOLD SEPARAT

AXLE wheel

1шт.

5

ST2118

TAPERED BEARING,1.75" ID x 3.27" OD x 0.9375"

CONE bearing

2шт.

118984A1

HUB,Assembly

HUB ASSEMBLY axle, front, used with 118986A1 axle assembly, Includes: Ref. 6 and 7

1шт.

118985A1

HUB,Assembly

HUB ASSEMBLY axle, rear, used with 118987A1 axle assembly, Includes: Ref. 6 and 7

1шт.

6

NSS

NOT SOLD SEPARAT

HUB axle

1шт.

7

130503H

BEARING CUP

CUP tapered roller bearing

2шт.

8

D53767

OIL SEAL,57.15mm ID x 85.75mm OD x 11mm Thk

oil

2шт.

9

D134202

SPACER,44.5mm ID x 57.23mm OD x 16mm L

axle, front

1шт.

10

D134203

DRIVE SPROCKET

SPROCKET axle, front, used with 118986A1 axle assembly

1шт.

11

D135527

DRIVE SPROCKET

SPROCKET axle, rear, used with 118987A1 axle assembly

1шт.

12

25-1314

SLOTTED NUT,7/8"-14, G5

NUT hex, slotted, 7/8 NF

1шт.

13

D53273

WASHER,23.02mm ID x 57.15mm OD x 1.41mm Thk

special, 0.1562 inch, 3.96 mm thick

1шт.

14

432-1024

COTTER PIN,5/32" x 1 1/2"

5/32" x 1 1/2"

1шт.

15

113706A1

LARGE PLATE

GASKET axle, steel

1шт.

Included with P/N 123854A1 axle kit.

1шт.

16

238-5267

O-RING,0.139" Thk x 8.234" ID, -267, Cl 5, 75 Duro

Sprocket -267, 70 Duro, 8.234" ID x .139" Thk

1шт.

Included with P/N 123854A1 axle kit.

1шт.

17

D124615

CHAIN (CE)

CHAIN ASSEMBLY endless, 74 pitch, right hand side of machine, front

1шт.

18

H437278

CHAIN (CE)

CHAIN ASSEMBLY endless, 60 pitch, left hand side of machine, front, not shown

1шт.

19

H437279

CHAIN (CE)

CHAIN ASSEMBLY endless, 68 pitch, left hand side of machine, rear, not shown

1шт.

20

H437281

CHAIN (CE)

CHAIN ASSEMBLY endless, 54 pitch, right hand side of machine, rear

1шт.

21

495-21056

WASHER,1/2"

flat, 9/16 x 1-3/8 x 3/32 inch

2шт.

22

14-816

BOLT,Hex, 1/2" - 20 x 1", Gr 5

hex, 1/2 NF x 1 inch

2шт.

23

492-11038

LOCK WASHER,3/8"

12шт.

24

425-106

NUT,3/8"-16, Cl 5

16шт.

25

D138562

PLATE

hydraulic motor, left hand

1шт.

26

F23214

WHEEL NUT

special, wheel

24шт.

27

195-2051

WASHER,17/32" x 13/16" x .060"

flat, 17/32 x 1-1/8 x 1/8 inch

2шт.

28

495-81025

WASHER,13.49mm ID x 31.75mm OD x 4.93mm Thk

flat, 17/32 x 1-1/4 x 5/32 inch

20шт.

Included with P/N 123854A1 axle kit.

1шт.

29

426-822

BOLT,Hex, 1/2" - 13 x 1-3/8", Gr 8

hex flange head, 1/2 NC x 1-3/8 inch, grade 8

20шт.

Included with P/N 123854A1 axle kit.

1шт.

30

D76459

DRIVE SPROCKET

SPROCKET drive

2шт.

31

231-5146

FLANGE NUT,3/8"-16

4шт.

32

H674085

LARGE PLATE

PLATE hydraulic motor, right hand

1шт.

33

113-2296

BOLT,Hex, 3/8" - 16 x 2", Gr 5, Full Thd

4шт.

34

D137477

GASKET

plate

2шт.

35

496-21041

WASHER,13/32" x 13/16" x .089", HDN

flat, hardened, 13/32 x 13/16 x 3/32"

12шт.

36

F44567

NUT plug, axle, 1/2 NC

20шт.

Included with P/N 123854A1 axle kit.

1шт.
