Запчасти Case 1816 (21A) - D61880 STARTER, TECUMSEH #33835 - SQUARE HOUSING (10) - ENGINE

D61880

STARTING MOTOR

STARTER motor, electrical, Incl. Ref. 1 - 19

1шт.

1

D61023

NUT

lock, special

4шт.

2

D61879

CAP

commatator end

1шт.

3

D61878

STUD

cap retaining

2шт.

4

D61877

WASHER thrust

1шт.

D61026

HOUSING

ASSEMBLY, starter, Incl. Ref. 5 - 11

1шт.

5

NSS

NOT SOLD SEPARAT

HOUSING starter

1шт.

6

C16064

NUT

hex, special

2шт.

7

C16069

WASHER

special

1шт.

D61881

BRUSH, COMMUTATOR

KIT, card and brush, Incl. Ref. 8 - 11

1шт.

8

NSS

NOT SOLD SEPARAT

CARD

1шт.

D61881

BRUSH, COMMUTATOR

KIT, spring and brush, Incl. Ref. 9 - 11

1шт.

9

NSS

NOT SOLD SEPARAT

BRUSH double

1шт.

10

NSS

NOT SOLD SEPARAT

BRUSH single

2шт.

11

D61883

SPRING

brush

4шт.

12

D61025

ARM ASSY.

ARMATURE starter

1шт.

13

D61024

CAP

drive end

1шт.

14

D61017

CAP

COVER dust

1шт.

15

D61018

RING

retaining

1шт.

16

D61019

SPRING

RETAINER spring

1шт.

17

D61020

SPRING

bendex

1шт.

18

D61021

GEAR

drive

1шт.

19

D61022

DISC

NUT engaging

1шт.
