Запчасти Case SV340 (55.518.010[03]) - WASHER RESERVOIR, REAR (55) - ELECTRICAL SYSTEMS

1

84272827

RIVET,Flat Flg Head, 12.7mm OD x 17.4mm L

2шт.

2

84285452

HOSE WASHER,4mm ID x 672mm L, SAE J1037

Rear Windshield

1шт.

3

84322854

FOAM INSULATION,684mm L x 6mm W x 3mm Thk

Cut to Length, 140mm

1шт.

4

84326923

BRACKET

Washer Bottle

2шт.

5

L11541

CABLE TIE,203.2mm L, Nylon

2шт.

6

84469613

TRIM,Bulk 300 FT

Cut to Length, 1580mm

1шт.

7

84582320

PANEL

Rear Trim, RH, NH Gray, Years: -02-OCT-16

1шт.

7

48000508

PANEL

Rear Trim, RH, Fiat Gray, Start Year: 03-OCT-16

1шт.

8

84582321

PANEL

Rear Trim, LH, NH Gray, Years: -02-OCT-16

1шт.

8

48000511

PANEL

Rear Trim, LH, Fiat Gray, Start Year: 03-OCT-16

1шт.

9

84605090

PANEL

Rear Trim, Center, NH Gray, Years: -02-OCT-16

1шт.

9

48000504

PANEL

Rear Trim, Center, Fiat Gray, Start Year: 03-OCT-16

1шт.

10

86620930

FASTENER,Push-In, 1.10" L, Nylon

14шт.

11

87682398

SCREW,Torx, Round HD, M6 x 16mm, Cl 10.9

2шт.

12

87335499

SWITCH

Rocker, Windshield Wiper/Washer

1шт.

13

NSS

NOT SOLD SEPARAT

Bottle, Washer. Incl in 17

1шт.

14

84326892

GROMMET

Bottle, Washer Pump

1шт.

15

84326893

WATER PUMP

Bottle, Washer

1шт.

16

84389235

FILLER CAP,2-1/4" Female Threads

Bottle, Washer

1шт.

17

84389613

BOTTLE

Assy, Incl 13 - 16

1шт.
