Артикул
Название
Примечание
Количество
1
280476
SELF-TAP SCREW,HWH, 3/8"-16 x 1"
4шт.
2
690681
HOSE,7.94mm ID x 3352.8mm L, SAE 30R7
Cut To Length Required
1шт.
5
9804256
BOLT,Hex, M6 x 1 x 20mm, Full Thd, Cl 8.8
4шт.
6
84259663
CABLE TIE,228.6mm L, Nylon, Black
4шт.
7
84268571
SENDER UNIT
Fuel Level, Incl 29
1шт.
8
84338049
MOUNTING PLATE
Sender Retaining
1шт.
9
84350217
FITTING,Fuel, 90 Degree Elbow, 5/16" Hose Barb x 5/16" Voss
1шт.
10
84350218
FITTING,Fuel, 90 Degree Elbow, 5/16" Hose Barb x 3/8" Voss
2шт.
11
84367737
LOCK WASHER,22.6mm OD x 1.27mm Thk
Fuel Cap Locking
1шт.
12
84370069
CHAIN
Fuel Cap
1шт.
13
84510421
FUEL TANK
Complete
1шт.
14
84548963
FITTING,90 Degree, Fuel, 3/8"
Fuel
1шт.
15
84553918
FITTING,90 Degree Quick Connect, 9.89mm Hose Bead
Fuel
1шт.
16
84553984
FUEL FILTER
WIF, Rear Door, Years: -03-OCT-13
1шт.
17
47542915
FUEL FILTER
WIF, Rear Door, Start Year: 04-OCT-13
1шт.
17
84567565
BRACKET
ECU Mounting
1шт.
87532034
CLAMP,15.9mm, Coat, 7.1mm Bolt Hole, P Type
Not shown, top of bracket for fuel line
1шт.
18
84591613
FITTING,Str, 7/16" Hose Barb x 1/4" NPTF, Brass
1шт.
19
84592507
HOSE,11.11mm ID x 250mm L, SAE 30R7
Fuel Line, Bulk, Cut To Length Required
1шт.
20
84592544
FUEL PUMP,12V, 1.4A
Lift, Years: -03-OCT-13
1шт.
21
84602030
PAD
Foam
2шт.
22
86619800
FLANGE NUT,M6 x 1, Cl 8
2шт.
23
87037711
SPRING NUT,U, Multi-Thd Sht, M8 x 1.25, PLN
2шт.
24
87054825
SUPPORT
Tank
1шт.
25
87436932
CLAMP,13.9mm - 15.5mm, Spring
3шт.
26
87443510
HOSE CLAMP,18.4mm Static ID x 15mm W
2шт.
27
87702286
TRIM,Bulk, 1/8" x 30480mm L
1шт.
28
L11541
CABLE TIE,203.2mm L, Nylon
4шт.
29
84485157
SEAL
Fuel Level Sender
1шт.
Выбрано товаров: 31
