Артикул
Название
Примечание
Количество
1
47524388
KIT
Complete HVAC, Incl 2 - 124
1шт.
2
L18331
CABLE TIE,375.9mm L, Nylon, Black
2шт.
3
L11541
CABLE TIE,203.2mm L, Nylon
3шт.
4
D39696
CLAMP,25.40mm - 13.49mm Bolt, CTD
4шт.
5
412679A2
SPRING,Extension, 22.5mm OD x 173mm L
2шт.
6
400472A1
SPRING,10mm Rod, 38.1mm Stroke
1шт.
7
348452A1
FASTENER,Push-In, 37mm L, Nylon
10шт.
8
229197A1
SQUARE NUT,M8 x 1.25, Cl 8
2шт.
9
127083A1
ELBOW,16mm OD x 17mm OD Bead
2шт.
10
87669161
VENT
Global Louver
6шт.
11
87655046
SPECIAL WASHER,10.65mm ID x 23mm OD x 2.2mm Thk
1шт.
12
87655042
SPECIAL WASHER,8.8mm ID x 17.5mm OD x 2.2mm Thk
2шт.
13
87606706
PULLEY,78.49mm OD
1шт.
14
87595771
ISOLATOR,200mm L x 50mm W x 3.2mm Thk
1шт.
15
87582270
BLOCK
Idler Adjust
1шт.
16
87567192
HEATER HOSE,5/8” Bulk Roll 500 FT, Return
Cut to Length, 2600mm
1шт.
18
87520839
VALVE
Package
1шт.
19
87443511
CLAMP,22mm - 26mm, CTB-24, Style C
12шт.
20
87441006
TUBE,4.6mm ID x 1350mm L
1шт.
21
87355337
RELAY,12V, 45A
1шт.
22
87310592
JAM NUT,7/16" - 28, Gr 5
2шт.
23
87036224
BOLT,Flng, M4 x 16mm, Cl 4.8
2шт.
24
87028323
HEX SOC SCREW,Btn Head, M8 x 1.25 x 25mm, Cl 8.8
4шт.
25
87016586
SPRING NUT,Multi-Thd, M8 x 1.25
4шт.
26
87015931
BOLT,Hvy Hex, M6 x 35mm, Cl 8.8
4шт.
27
87000227
SWITCH, A/C HIGH PRE
5000 PSI Max
1шт.
28
86729675
SWITCH,5000 Ohm
Tempurature
1шт.
30
86729669
SWITCH
Blower
1шт.
32
86637976
CLAMP,19mm, Coat, 8.7mm Bolt Hole, P Type
1шт.
33
86636815
CARRIAGE BOLT,Sq Nk, M8 x 25mm, Cl 8.8, Full Thd
1шт.
34
86625074
SPRING NUT,Multi-Thd, M8 x 1.25
4шт.
35
86625073
SPRING NUT,M6 x 1
4шт.
36
86625034
HOSE CLAMP,90.4mm - 114.3mm, Worm Gear
2шт.
37
86624185
WASHER,8.8mm ID x 17.5mm OD x 2mm Thk
1шт.
38
86624183
WASHER,6.6mm ID x 25mm OD x 1.6mm Thk
4шт.
39
86619800
FLANGE NUT,M6 x 1, Cl 8
2шт.
40
86530043
FITTING,5/8” Y-Fitting
Y
1шт.
41
86512554
NUT,M10 x 1.5, Cl 10
2шт.
43
86511841
BOLT,Flng, M8 x 1.25 x 16mm, Full Thd, Cl 8.8
3шт.
44
86511833
SCREW,Phillips Drive, Pan HD, M6 x 40mm
4шт.
45
86405134
PULLEY
A/C
1шт.
46
84559122
BRACKET
Water Valve & Dryer
1шт.
47
84416164
FOAM INSULATION
RH Upper Chassis
2шт.
48
84416163
FOAM INSULATION
RH Upper Chassis
2шт.
49
84411489
FOAM INSULATION
Center Upper Chassis
1шт.
50
84387904
COMPRESSION SPRING,Extension, 225mm OD x 100mm L
1шт.
51
84380240
BRACKET
Relay
1шт.
52
84378693
BRACKET
Compressor Pivot, Gray
1шт.
53
84370705
BRACKET
147mm L
1шт.
54
84370302
FOAM INSULATION
HVAC Box
1шт.
55
84362126
FOAM INSULATION
Roof
1шт.
56
84361522
BRACKET
L
1шт.
57
84357840
HOSE,15.5mm ID x 2740mm L
1шт.
58
84357678
HOSE,15.5mm ID x 1635mm L
1шт.
59
84347258
DECAL
HVAC
1шт.
60
84323065
BELT
A/C Drive
1шт.
61
84322901
PLATE
Cover, Yellow
1шт.
62
84322838
PLATE
Cover, Tan
1шт.
63
84321278
BRACKET, PIVOT
Compressor, Gray
1шт.
64
84286072
SPRING
Throttle
1шт.
65
84285339
SELF-TAP SCREW,Hex, M8 x 1.25 x 15mm
4шт.
66
84280313
AIR DUCT
Intake
1шт.
67
84272827
RIVET,Flat Flg Head, 12.7mm OD x 17.4mm L
4шт.
68
84200938
CLAMP
Throttle Cable
1шт.
69
82012869
CABLE TIE,300mm L, Nylon, Black
2шт.
70
48063671
INSTRUCTION
Heat/HVAC Trim, Sheet
1шт.
71
48052200
TRIM PANEL
Rear, Lapbar, Fiat Gray
1шт.
72
48043997
INSTRUCTION
ISM Heater Hose, Sheet
1шт.
73
48043558
INSTRUCTION
ISM HVAC Hose Component, Sheet
1шт.
74
48037259
A/C HOSE
Discharge
1шт.
75
48033462
SEALING STRIP,684mm L
684mm L
1шт.
76
48031374
TRIM,Flare, 790mm L
Flare, 790mm L
2шт.
77
47997458
INSTRUCTION
HVAC, Sheet
1шт.
78
47984178
HEATER
W/ A/C
1шт.
79
47939973
A/C HOSE
Discharge
1шт.
80
47939967
A/C HOSE
Discharge
1шт.
81
47939965
A/C HOSE
Liquid
1шт.
82
47929817
WIRE HARNESS
HVAC Jumper
1шт.
83
47921777
BRACKET
HVAC Support
1шт.
84
47919015
DUCT
RH Air, Trim, Fiat Gray
1шт.
85
47919014
DUCT
LH Air, Trim, Fiat Gray
1шт.
86
47918644
FASTENER,Pine Tree, 26.9mm L, Nylon
7шт.
87
47890516
INSTRUCTION
HVAC Bracket Components, Sheet
1шт.
88
47821526
RECEIVER-DRYER
Horizontal
1шт.
89
47741863
AIRCOND. COMPRESSOR
Assy
1шт.
90
47707866
FITTING,5/8” Hose Barb Union
1шт.
91
47641601
BRACKET
LH, Condenser, Gray
1шт.
92
47641594
BRACKET
RH, Condenser, Gray
1шт.
93
47627999
HEATER HOSE,15.5mm ID, Formed
1шт.
94
47537889
GAS STRUT,372mm Extended, 327mm Compressed
Enclosed Cab
1шт.
95
47473794
REINFORCEMENT
LH, Tilt Hood, Gray
1шт.
96
47473791
REINFORCEMENT
RH, Tilt Hood, Gray
1шт.
97
47462652
BRACKET
LH, Condenser, Gray
1шт.
98
47388959
BRACKET
RH, Condenser, Gray
1шт.
99
47376521
CONDENSER
Assy
1шт.
100
9860169
RIVET,10-32 Thread, 19.6mm Shoulder
1шт.
101
9844532
BRACKET
L
1шт.
102
9824642
BOLT,M12 x 1.75 x 42.68mm, Cl 10.9
3шт.
103
9804278
FLANGE NUT,M10 x 1.5, Cl 8
3шт.
105
9804276
FLANGE NUT,Hex, M6 x 1, Cl 8
5шт.
106
9804262
BOLT,M10 x 39.2mm, Cl 8.8
1шт.
107
9804261
BOLT,Hex, M10 x 25mm, Cl 8.8, Full Thd
1шт.
108
9804258
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
5шт.
111
7120985
BOLT,Hex, M10 x 115mm, Cl 10.9
1шт.
112
725403
BOLT,Hex, M8 x 1.25 x 100mm, Cl 8.8, Full Thd
1шт.
114
350459
CARRIAGE BOLT,Rnd Head, M10 x 1.5 x 50mm, Full Thd, Cl 8.8
1шт.
115
287644
FITTING,90 Degree, 5/8" Hose x 3/8" NPTF Beaded
1шт.
116
285072
WASHER,10.3mm ID x 22.2mm OD x 2.7mm Thk
1шт.
117
263117
CABLE TIE,292.1mm L, Nylon, Black
7шт.
119
100012
NUT,M4 x 0.7, Cl 8
2шт.
120
88826
LOCK NUT,#10-24, GA
1шт.
121
84821
SCREW,Truss HD, #10 - 24 x 1/2"
1шт.
122
80707
WASHER,0.25" ID x 0.56" OD x 0.05" Thk
1шт.
124
13734
SPACER,6.52mm ID x 9.52mm OD x 3.43mm W
1шт.
Выбрано товаров: 124
