Запчасти Case SR250 (88.100.10[18]) - ENGINE ACCESSORIES EU/OPEN EU W/SOUND (SR220,SR250) (88) - ACCESSORIES

Схема запчастей Case SR250 - (88.100.10[18]) - ENGINE ACCESSORIES EU/OPEN EU W/SOUND (SR220,SR250) (88) - ACCESSORIES
6
2
xx.xxx.xx
7
17
14
3
11
xx.xxx.xx
12
15
xx.xxx.xx
4
13
16
5
1
xx.xxx.xx
home
10
9
8

Артикул

Название

Примечание

Количество

1

47488898

FAN,9 Blades, 480mm OD

Clockwise Pusher

1шт.

2

84373345

SPACER

Fan 32/33 MM

1шт.

3

86011090

BOLT,Hex Flng, M10 x 70mm, Cl 8.8

4шт.

4

84372988

FOAM INSULATION,584.4mm L x 67.5mm W x 50.8mm Thk

Fan RH

1шт.

5

84372973

FOAM INSULATION,264.4mm L x 87.2mm W x 25.4mm Thk

Fan LH

1шт.

6

84372981

FOAM INSULATION

Fan

1шт.

7

84373796

FOAM INSULATION

Hood

1шт.

8

84362125

FOAM INSULATION

Crossmember, used only with Open Cab

1шт.

9

84366338

FOAM INSULATION

LH Tower Front, Years: -13-JUL-15

1шт.

9

47886440

INSULATION

LH Tower Front, Start Year: 14-JUL-15

1шт.

10

84366337

FOAM INSULATION

Pad, Right Tower

1шт.

11

84366336

FOAM INSULATION

Chassis Front LH

1шт.

12

84366353

FOAM INSULATION

Heel Plate Horizontal

1шт.

13

84366352

FOAM INSULATION

Heel Plate Vertical

1шт.

14

84366339

FOAM INSULATION

LH Tower Mid

1шт.

15

84366341

FOAM INSULATION

LH Tower RR

1шт.

16

84366337

FOAM INSULATION

RH Tower Front

1шт.

17

87461957

STOP

Stop

1шт.

18

87595771

ISOLATOR,200mm L x 50mm W x 3.2mm Thk

Pad, Not Illustrated

1шт.

19

L18331

CABLE TIE,375.9mm L, Nylon, Black

Not Illustrated

2шт.

20

84372040

FOAM

Seat Pan, used only with Open Cab, Not Illustrated

1шт.

Выбрано товаров: 21
