Артикул
Название
Примечание
Количество
2
9804258
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
4шт.
3
47364444
HYDRAULIC CYLINDER,38.1mm Rod, 410mm Stroke
Bucket Cylinder, 38.1mm ID x 76.1mm Bore x 410mm Stroke
2шт.
See Figure 35.723.AA For Service Parts
1шт.
47364444R
LIFT CYLINDER
SR220 TIER 4A (7/12-), SV250 TIER 4 (1/13-)
2шт.
47364444C
LIFT CYLINDER
Return Number
1шт.
4
47364860
HYDRAULIC CYLINDER,44.4mm Rod, 817.9mm Stroke
Lift, 44.4mm Rod x 63.5mm Bore x 817.9mm Stroke
2шт.
See Figure 35.701.CB For Service Parts
1шт.
47364860R
LIFT CYLINDER
SR220 TIER 4A (1/13-)
2шт.
47364860C
LIFT CYLINDER
Return Number
1шт.
5
84238749
BOLT,Hex Flg, M16 x 210mm, Cl 10.9
2шт.
6
84248603
PIN,38.15mm OD x 137.9mm L
Lift Cylinder
2шт.
7
84255103
STRUT
Channel
1шт.
8
87016581
FLANGE NUT,M16 x 2, CI 10
2шт.
9
84391755
KIT
Radial Arm, Tan, Incl Decals and Instructions
1шт.
10
84308025
PIN,38.15mm OD x 280mm L
Chassis To Lift Cylinder
2шт.
11
84319704
PIN,50mm OD x 111mm L
Boom To Tip Cylinder
2шт.
12
84341462
PIN,38.15mm OD x 233.5mm L
Boom To Chassis
2шт.
13
84377147
STEP
Tan
1шт.
14
84467349
PIN,9.53mm OD x 76.2mm L
Snapper
1шт.
15
84530035
MOUNTING PLATE
Rear Mount
2шт.
16
85802403
PLUG,13mm OD
Loader Prop
1шт.
17
86507311
BOLT,Hex, M10 x 80mm, Cl 8.8
4шт.
18
86512554
NUT,M10 x 1.5, Cl 10
4шт.
19
86625074
SPRING NUT,Multi-Thd, M8 x 1.25
4шт.
20
86632531
SNAP RING,#150, Ext
4шт.
21
86632586
WASHER,1.53" ID x 2.5" OD x 0.11" Thk
1.531" x 2-1/2" x 0.109", CST, ZND
10шт.
22
186977A1
WASHER,17mm ID x 70mm OD x 4.5mm Thk
Base End of Tip Cyl, Not Illustrated, Start Year: 31-JUL-13
2шт.
Выбрано товаров: 29
