Артикул
Название
Примечание
Количество
1
84391755
KIT
Frame,KIT
1шт.
2
84290567
HYDRAULIC CYLINDER,Double Acting, 34.9mm Rod, 410mm Stroke
Bucket
2шт.
2
47364446R
HYDRAULIC CYLINDER
Reman for New PN 84290567
2шт.
2
47364446C
HYDRAULIC CYLINDER
Return Number
2шт.
3
84303687
CYLINDER,Double Acting, 38.1mm Rod, 804.9mm Stroke
Lift
2шт.
4
86632531
SNAP RING,#150, Ext
4шт.
5
84248603
PIN,38.15mm OD x 137.9mm L
Lift Cylinder
2шт.
6
84308025
PIN,38.15mm OD x 280mm L
Chassis to Lift Cylinder
2шт.
7
86507311
BOLT,Hex, M10 x 80mm, Cl 8.8
4шт.
8
86512554
NUT,M10 x 1.5, Cl 10
4шт.
9
85802403
PLUG,13mm OD
Pad, Loader Prop
1шт.
10
84319704
PIN,50mm OD x 111mm L
Boom to Tip Cylinder
2шт.
11
84238749
BOLT,Hex Flg, M16 x 210mm, Cl 10.9
2шт.
12
84341462
PIN,38.15mm OD x 233.5mm L
Boom Chassis
2шт.
14
84346854
STEP
Loader
1шт.
15
84309995
STRUT
Channel Safety Red
1шт.
16
84467349
PIN,9.53mm OD x 76.2mm L
Snapper
1шт.
17
87016581
FLANGE NUT,M16 x 2, CI 10
2шт.
18
86625074
SPRING NUT,Multi-Thd, M8 x 1.25
4шт.
19
9804258
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
4шт.
20
86632586
WASHER,1.53" ID x 2.5" OD x 0.11" Thk
14шт.
21
84577922
HUB,63.4mm OD x 96.2mm L
Main Frame
2шт.
22
84251365
TUBE
Loader Arm Pivot
2шт.
23
86521978
HUB,38.23mm ID x 69.85mm OD x 12.7mm L
2шт.
24
84577923
HUB,44mm ID x 69.85mm OD x 246mm L
Boom to Tip Cyl
2шт.
Выбрано товаров: 27
