Запчасти Case SR130 (10.220.AA[02]) - THROTTLE CONTROL LINKAGE (SR130,SR150) (10) - ENGINE

1

9637692

NUT,3/8"-16, Gr B

1шт.

2

9804276

FLANGE NUT,Hex, M6 x 1, Cl 8

2шт.

3

47408125

THROTTLE CONTROL,3092mm L

Hand Control Incl 4,5

1шт.

4

182048A1

GROMMET

1шт.

5

84270677

KNOB,M12 x 1.75

Throttle Control

1шт.

6

47536465

MOUNT

Hand Throttle

1шт.

7

86511839

BOLT,Hvy Hex, M6 x 30mm, Cl 8.8

2шт.

8

86533830

BOLT,Hex, 3/8" - 16 x 2", Gr 5

1шт.

9

86637978

CLAMP,9.5mm, Coat, 8.7mm Bolt Hole, P Type

1шт.

10

84305556

SCREW,Round HD, M6 x 1 x 25mm, Cl 10.9

2шт.

11

86639010

CLAMP,9.5mm, Coat, 13.5mm Bolt Hole, P Type

1шт.

12

84272827

RIVET,Flat Flg Head, 12.7mm OD x 17.4mm L

2шт.

13

87022737

SPACER,11.1mm ID x 15.9mm OD x 25mm L

1шт.

14

87655046

SPECIAL WASHER,10.65mm ID x 23mm OD x 2.2mm Thk

2шт.
