Артикул
Название
Примечание
Количество
1
87710312
SERVICE KIT
ROPS; Incl ROPS, Decal - Warning, Decal - General Instructions, ROPS Model And Approval Plate
1шт.
2
419434A1
INSERT
Threaded, M6
10-20шт.
4
140016
WASHER,M8 x 16mm OD x 1.6mm Thk
12-14шт.
5
86505868
SERRATED NUT,Hex, M8 x 1.25, Cl 8
16-20шт.
6
86625129
PLUG,Dome, 1" Hole, Nylon
2шт.
6
87499075
DECAL
Blank Decal, Gray
1шт.
7
87671888
PANEL
Rear Seat; If Used
1шт.
7
87473787
Rear Seat Panel
1шт.
8
9847468
BOLT,Hex, M16 x 2 x 70mm, Cl 10.9
2шт.
10
391703A2
WASHER,16.67mm ID x 55mm OD x 6.35mm Thk
2шт.
11
D143415
SNAP RING,0.50” ID, Klipring
2шт.
12
86632589
WASHER,0.53" ID x 1.06" OD x 0.1" Thk
2шт.
13
87620895
BUSHING,12.98mm ID x 19.11mm OD x 23.1mm L
Lap Bar Pivot
2шт.
14
87645117
DRAWBAR CLAMP
Seat Bar Pivot, RH; If Used
1шт.
14
87473777
BRACKET, PIVOT
PIVOT BRACKET Seat Bar Pivot, RH
1шт.
16
86511444
FLANGE NUT,Hex, M6 x 1
4-8шт.
17
86588450
WASHER,6.6mm ID x 12mm OD x 1.6mm Thk
4-8шт.
18
87684077
PANEL
RH; If Used
1шт.
18
87482188
PANEL
Extention Panel RH
1шт.
19
87684078
PANEL
LH; If Used
1шт.
19
87482190
PANEL
Extention Panel LH
1шт.
20
9804256
BOLT,Hex, M6 x 1 x 20mm, Full Thd, Cl 8.8
If Used
2шт.
21
43127
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8
If Used
10шт.
22
87639899
CYLINDER
1шт.
23
189609A1
BALL STUD,M8 x 1.25
Ball
2шт.
24
87460732
PANEL
Solid Panel; If Used
1-2шт.
24
87694082
PANEL
Perforated Panel; If Used
2шт.
26
408117A2
THUMB SCREW,M8 x 1.25 x 15mm
Thumb, M8; If Used
4шт.
26
120103
BOLT,M8 x 1.25 x 16mm, Cl 8.8
2-4шт.
27
442856A1
SEALING WASHER,7.11mm ID x 12.7mm OD x 0.79mm Thk
2-4шт.
28
87639914
STOP
Seat Bar Stop
2шт.
29
87639912
KNOB
2шт.
30
REF
INSTRUCTION
Seat Bar; See Fig 09-27
1шт.
31
87713388
MOLDING
Floor Seal
1шт.
33
86512554
NUT,M10 x 1.5, Cl 10
2шт.
35
120070
BOLT,Hex, M10 x 1.5 x 60mm, Cl 8.8
1шт.
36
282002A2
GAS STRUT
1шт.
37
144345A3
PIVOT PIN,25.4mm OD x 825mm L
1шт.
38
827695C1
CIRCLIP
2шт.
39
87672170
MOLDING
Cup Holder
1шт.
40
86637935
BOLT,Hex, 1/4" - 20 x 1", Gr 8
If Used
2шт.
40
88542
BOLT,Hex, 1/4"-20 x 1/2", Gr 5
2шт.
41
87016587
WASHER,0.27" ID x 0.62" OD x 0.05" Thk
2шт.
42
304061A1
BUMPER,Rubber
Rubber, Cup Holder
4шт.
43
NSS
NOT SOLD SEPARAT
Plate, ROPS Certification
1шт.
44
87645118
DRAWBAR CLAMP
Seat Bar Pivot, LH; If Used
1шт.
44
87473775
BRACKET, PIVOT
PIVOT BRACKET Seat Bar Pivot, LH
1шт.
45
87051110
DOOR SWITCH
Seat Bar
1шт.
46
H435814
U-BOLT
1шт.
46
87319756
SCREW,Phillips Drive, Pan HD, #6 - 32 x 1-3/8"
#6-32 x 1.375; If used
2шт.
47
280859
NUT,Keps, #6-32
2шт.
48
87713678
GROMMET
1шт.
49
87619939
ARM
Upper Lap Bar LH
1шт.
50
87619938
ARM
Upper Lap Bar RH
1шт.
51
87619935
BAR
Lower Section Lap Bar
1шт.
52
86511829
SCREW,Phil Pan Hd, M6 x 16mm, Cl 4.8, Full Thd
4шт.
53
87436247
THREADED INSERT
M6 Blind Threaded Fastener
8шт.
54
414635A1
COVER,25.4mm OD x 0.51mm Thk
Cover, 25.4 Dia Lexan Gray
4-16шт.
55
86511189
WASHER,0.16" ID x 0.38" OD x 0.05" Thk
2шт.
Выбрано товаров: 66
