1
H169920
BALL JOINT
1шт.
2
86976064
JAM NUT,Jam, 1/4"-28, G5
2шт.
3
87667339
BRACKET
Throttle Bracket
1шт.
4
86517328
LOCK WASHER,6.1mm ID x 11.8mm OD x 1.7mm Thk
2шт.
5
120100
BOLT,M6 x 20mm, Cl 8.8
2шт.
6
88098
JAM NUT,Jam, 1/4"-28, G2
1шт.
7
80682
LOCK WASHER,1/4"
1шт.
8
694371
SPACER,9.77mm ID x 15.87mm OD x 5.03mm Thk
1шт.
9
86636815
CARRIAGE BOLT,Sq Nk, M8 x 25mm, Cl 8.8, Full Thd
1шт.
10
87028524
CLAMP,11.1mm, Coat, 10.3mm Bolt Hole, P Type
1шт.
11
9628098
NUT,M8 x 1.25, Cl 10
1шт.
12
86625263
WASHER,9mm ID x 20mm OD x 1.6mm Thk
1шт.
13
87666100
ROD
Throttle Rod, 1343mm (52 7/8 in.) Length; No Longer Used, Order 87734197
1шт.
13
87734197
ROD
Throttle Rod, 1355mm (53 3/8 in.) Length
1шт.
14
87622861
CLEVIS PIN
1шт.
REF
INSTRUCTION
Throttle Control; Incl 15-25
1шт.
15
A177436
KNOB
1шт.
16
D124939
SPRING
1шт.
17
43117
SCREW,Hex, M6 x 1.0 x 30mm, Cl 8.8
1шт.
18
186904A1
CONTROL LEVER
1шт.
19
87743040
BRACKET
Foot Throttle; Replaces 87712224
1шт.
20
187035A2
SLEEVE
1шт.
21
86625256
WASHER,13.3mm ID x 28.5mm OD x 4mm Thk
2шт.
22
87612749
BOLT,Hex, M12 x 60mm, Cl 10.9
1шт.
23
186905A1
BUSHING
1шт.
24
R14771
WASHER
1шт.
25
1342374C1
DISC
1шт.
26
D23693
AXLE PIN
If Used
1шт.
26
87482654
CLEVIS PIN
1шт.
27
323657A1
PAD
Pad, Foot Throttle
1шт.
