(02-34) - WATER PUMP - CONTROL

Запчасти Case 435 (02-34) - WATER PUMP - CONTROL (02) - ENGINE

Схема запчастей Case 435 - (02-34) - WATER PUMP - CONTROL (02) - ENGINE
6
5
3
4
2
1
7
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

86982450

V-BELT

1шт.

2

2853006

PULLEY,65mm OD

1шт.

3

REF

INSTRUCTION

See Figure 04-02, Alternator

1шт.

4

REF

INSTRUCTION

See Figure 02-35, Fan Drive

1шт.

5

REF

INSTRUCTION

See Figure 02-27, Oil Pump

1шт.

6

REF

INSTRUCTION

See Figure 02-23, Pulley, Crankshaft

1шт.

7

REF

INSTRUCTION

See Figure 02-31, Water Pump

1шт.

Выбрано товаров: 7
