Запчасти Case 435 (09-50) - 87526346 HVAC KIT (09) - CHASSIS

Схема запчастей Case 435 - (09-50) - 87526346 HVAC KIT (09) - CHASSIS

Артикул

Название

Примечание

Количество

87526346

KIT

HVAC, Includes: Ref. 1 - 114 & Installation Instructions

1шт.

1

43129

BOLT,Hex, M8 x 1.25 x 40mm, LH Thd, Cl 8.8

4шт.

Use Qty. 3 for 435 & 445

1шт.

2

43139

BOLT,M10 x 1.5 x 25mm, Cl 8.8

1шт.

3

43234

BOLT,Hex, M8 x 1.25 x 25mm, Cl 10.9, Full Thd

2шт.

4

43235

BOLT,Hex, M8 x 1.25 x 30mm, Cl 10.9, Full Thd

4шт.

5

43465

CARRIAGE BOLT,Short NK, M8 x 30, Cl8.8, Full Thd

2шт.

Use for 445 & 450

1шт.

6

80681

LOCK WASHER,5/16"

4шт.

7

87364

WASHER,0.53" ID x 1.06" OD x 0.1" Thk

1шт.

8

88871

NUT,1/2"-13, GC

1шт.

9

120103

BOLT,M8 x 1.25 x 16mm, Cl 8.8

2шт.

10

140017

WASHER,M10 x 20mm OD x 2mm Thk

6шт.

11

140028

WASHER,10.2mm ID x 18.1mm OD x 2.2mm Thk

4шт.

12

242680

HYD CONNECTOR,7/8" - 14 JIC x 1/2" - 14 NPT

1шт.

13

280486

CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1", Gr 5, Full Thd

1шт.

14

281032

BOLT,Hex, 1/4" - 20 x 3/4", Gr 8, Full Thd

5шт.

15

300381

BOLT,Hex, M8 x 1.25 x 35mm, Cl 8.8

1шт.

16

322358

BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk

2шт.

Use for 445 & 450

1шт.

17

412250

NUT,M8 x 1.25, Cl 8

6шт.

18

642560

FITTING,5/8" Hose x 3/8" NPTF Beaded

3шт.

19

9515003

BOLT,Hex, M10 x 1.5 x 30mm, Cl 10.9

3шт.

20

9706690

NUT,M8 x 1.25, Cl 8

10шт.

Use Qty. 7 for 435 & 465

1шт.

21

9706732

CLAMP,19mm ID, 8.7mm Bolt Hole, P Type

1шт.

22

9804256

BOLT,Hex, M6 x 1 x 20mm, Full Thd, Cl 8.8

2шт.

23

9804277

FLANGE NUT,Hex, M8 x 1.25, Cl 8

2шт.

24

9827902

CLAMP,25.4mm, Coat, 10.3mm Bolt Hole, P Type

4шт.

25

86025725

BOLT,Hex, M5 x 40mm, Cl 8.8

4шт.

26

86050279

FLANGE NUT,M10 x 1.5, Cl 10

3шт.

27

86500940

SELF-TAP SCREW,Hex Wash Hd, #10 x 3/4"

3шт.

28

86508621

BOLT,Hex, M10 x 130mm, Cl 10.9

1шт.

29

86511444

FLANGE NUT,Hex, M6 x 1

6шт.

30

86512420

CARRIAGE BOLT,Rnd Head, M8 x 1.25 x 20mm, Full Thd, Cl 8.8

7шт.

Use Qty. 6 for 450

1шт.

31

86588450

WASHER,6.6mm ID x 12mm OD x 1.6mm Thk

4шт.

32

86592710

WASHER,6.4mm ID x 17mm OD x 3mm Thk

4шт.

33

86624185

WASHER,8.8mm ID x 17.5mm OD x 2mm Thk

6шт.

34

86625263

WASHER,9mm ID x 20mm OD x 1.6mm Thk

12шт.

Use qty. 9 for 435 & 445

1шт.

35

86625481

RECEIVER-DRYER

1шт.

36

86625515

PRESSURE SWITCH

A/C

1шт.

37

86639409

DECAL

A/C Specs.

1шт.

38

86979986

WASHER,0.34" ID x 1.25" OD x 0.06" Thk

3шт.

39

86977786

BOLT,Hex, M6 x 1 x 25mm, Cl 8.8

4шт.

Use Qty. 2 for 435 & 445

1шт.

40

87000312

CABLE TIE,4.8mm W x 203.2mm OAL, Nylon

CABLE STRAP

10шт.

Use Qty. 6 for 450 & Qty. 8 for 465

1шт.

41

87013357

WASHER,5.5mm ID x 15mm OD x 1.6mm Thk

4шт.

42

87015284

WASHER,8.8mm ID x 21.5mm OD x 2.5mm Thk

4шт.

43

87015763

BOLT,Hex, M10 x 40, 10.9, Full Thd

2шт.

44

87016587

WASHER,0.27" ID x 0.62" OD x 0.05" Thk

5шт.

45

87026034

AIRCOND. COMPRESSOR,12V, W/ Clutch, W/ Pulley

A/C

1шт.

87026034R

REMAN-A/C COMPRESSOR,12V, W/ Clutch, W/ Pulley

435 BSN N7M425032 (3/04-12/07)

1шт.

87026034C

CORE-A/C COMPRESSOR

Return number

1шт.

46

87029162

LINING

Headliner

1шт.

47

87029784

BRACKET

Rear Heater

1шт.

48

87029785

BRACKET

Heater

2шт.

49

87029955

CLAMP,22.2mm, Coat, 10.3mm Bolt Hole, P Type

1шт.

50

87035708

SUPPORT

Window, Rear

1шт.

51

87035709

SUPPORT

Window, Rear

1шт.

52

87036359

PAD

2шт.

53

87036371

SEAL

Lower Side, ROPS

2шт.

54

87036372

SEALING STRIP

Lower Front, ROPS

1шт.

55

87036373

SEAL

Lower Side, ROPS

1шт.

56

87036932

BRACKET

1шт.

57

87301324

NUT,Spring, M5 x 0.8

4шт.

58

87340800

SPACER,5/8" Tube x 15.88mm

1шт.

59

87391944

PULLEY

A/C Compressor Drive

1шт.

60

87436117

A/C HOSE,12.7mm ID x 3657.6mm L

A/C

1шт.

Use for 435 & 445 Only

1шт.

61

87436118

A/C HOSE

A/C

1шт.

62

87436120

HOSE,7.92mm ID x 3657.6mm L

A/C

1шт.

63

87436121

HOSE,10.31mm ID x 1701.8mm L

A/C

1шт.

64

87436246

THREADED INSERT

2шт.

65

87437501

BRACKET

Receiver Dryer

1шт.

66

87438128

BELT,12.70 mm W

A/C Drive

1шт.

67

87438211

HEATER HOSE,15.88 mm ID x 2985.00 mm, SAE 20R3

Supply

1шт.

Use for 435 & 445 Only

1шт.

68

87438212

HEATER HOSE,15.88 mm ID x 1900.00 mm, SAE 20R3

Return

2шт.

69

87438213

HEATER HOSE,15.88mm ID x 3215mm L, SAE 20R3

Return

1шт.

70

87438318

SUPPORT

Headliner Front

1шт.

71

87439472

BRACKET

Water Valve & Dryer

1шт.

72

87439550

HARNESS

HVAC

1шт.

73

87439844

GUARD

ROPS Front

3шт.

74

87439845

GUARD

ROPS Rear Bottom

2шт.

Use Qty. 2 for 435, 450 & 465

1шт.

75

87439846

GUARD

ROPS Rear

2шт.

76

87439990

GUARD,46mm ID x 900mm L, Nylon Woven

Heater Hose

2шт.

77

87441006

TUBE,4.6mm ID x 1350mm L

A/C Hose

1шт.

Use Qty. 1 for 450

1шт.

78

87441937

VALVE

Ball, Heater Hose

1шт.

79

87443444

SLEEVE

Heat Protective

2шт.

80

87443511

CLAMP,22mm - 26mm, CTB-24, Style C

8шт.

Use for 435 & 445 Only

1шт.

81

87445754

ROD ASSY.

1шт.

82

87445908

HARNESS

Compressor

1шт.

Use for 435 & 445 Only

1шт.

83

87445909

HARNESS

Pressure Switch

1шт.

84

87450536

A/C HOSE,990.6/39 mm L

A/C Drain

2шт.

85

87450833

TAPE

2шт.

86

87457152

GUARD

Fan

1шт.

87

87457335

LOCKING BAR

1шт.

88

87459682

ROD ASSY.

1шт.

Use for 435 & 465 Only

1шт.

89

87460689

LOCK

A/C Hood

1шт.

Use for 450 & 465 Only

1шт.

90

87460803

HOOD ASSY.

1шт.

Use for 445 & 450 Only

1шт.

91

87460906

COVER

2шт.

92

87520839

VALVE

1шт.

93

87546926

BELT,12.70 mm W

Drive A/C

1шт.

94

87555246

CONTROL PANEL

HVAC

1шт.

Use for 450 & 465 Only

1шт.

95

87555249

SWITCH

A/C

1шт.

96

87563692

CONDENSER

A/C

1шт.

97

87574329

HOSE,7.94mm ID x 105.5mm L

A/C

1шт.

98

87574372

SPACER,6.8mm ID x 10.3mm OD x 19mm L

4шт.

99

87612366

HEATER TUBE

1шт.

100

87682495

AIR CONDITIONER,Assembly

A/C & Heater

1шт.

101

196050A1

PULLEY

Compressor Drive

1шт.

Use for 450 & 465 Only

1шт.

102

229197A1

SQUARE NUT,M8 x 1.25, Cl 8

2шт.

103

254697A1

SPACER

1шт.

104

295076A1

SEAL

ROPS Pivot Pin

2шт.

105

373200A2

GLASS

Rear Window

1шт.

106

373315A1

DOOR SEAL

2шт.

107

373316A1

DOOR SEAL

Rear Side

2шт.

108

400472A1

SPRING,10mm Rod, 38.1mm Stroke

Hood

1шт.

109

411345A1

LOCK NUT

1шт.

110

414635A1

COVER,25.4mm OD x 0.51mm Thk

4шт.

111

A149802

FUSE

1шт.

112

D143242

PLUG,7.1mm Dia Shank x 25.4mm OD Head x 23.1mm L

2шт.

113

H434289

MOUNTING CLIP,7/8”, Insulated, 1/2” Bolt

3шт.

Use for 435 & 445 Only

1шт.

114

H439303

CLIP

1шт.

Выбрано товаров: 137
