Артикул
Название
Примечание
Количество
1
87019071
HYDRAULIC HOSE
Supply And Return
2шт.
2
225529A1
CLAMP,Dual, 25.4mm ID
3шт.
3
257859A1
PLATE, SPACER,31.8mm W x 68mm L x 4.76mm Thk
PLATE,SPACER
3шт.
4
86625263
WASHER,9mm ID x 20mm OD x 1.6mm Thk
5шт.
6
87442186
HYD TUBE,25.4 mm OD x 593.2, 587.2 mm L
1шт.
7
87442187
HYD TUBE,25.4 mm OD
1шт.
8
87017999
SUPPORT
2шт.
9
87016401
HOSE
2шт.
10
87415965
CLAMP
1шт.
11
86624184
WASHER,9mm ID x 16mm OD x 1.6mm Thk
1шт.
13
276432A1
HOSE CLAMP
Clamp
1шт.
14
371108R1
SPACER,3/8" Pipe x .844"
1шт.
15
814-8045
BOLT,Hex, M8 x 1.25 x 45mm, Cl 8.8
2шт.
16
87412452
TUBE,25.40 mm OD x 1507.1, 479.1 mm L
1шт.
17
87412454
TUBE,25.40 mm OD x 1520.6, 414.1 mm L
1шт.
18
87412458
HYD TUBE,15.9 mm OD x 369.9, 37.6 mm L
Auxiliary
1шт.
19
87412456
HYD TUBE,15.9 mm OD x 369.9, 37.7 mm L
Auxiliary
1шт.
20
87412449
BRACKET
High Flow Quick Disconnect
1шт.
87426762
RING
Not Illustrated
1шт.
22
393394A1
COUPLING, BREAK AWAY
1/2; Female Quick Disconnect
1шт.
23
595460
BHD LOCK NUT,7/8" - 14
2шт.
24
87022672
QUICK MALE COUPLING
Male; Mating Connector For 87022672 (Male) Is 395267A1 (Female)
1шт.
25
86513144
BHD LOCK NUT,Blkhd, 1 5/16"-12
2шт.
26
87022671
COUPLING, QUICK, FEM
Female; Mating Conector For 87022671 (Female) Is 395268A1 (Male)
1шт.
27
87414769
SWITCH
High Flow
1шт.
28
9827902
CLAMP,25.4mm, Coat, 10.3mm Bolt Hole, P Type
2шт.
30
86624184
WASHER,9mm ID x 16mm OD x 1.6mm Thk
5шт.
31
9628098
NUT,M8 x 1.25, Cl 10
3шт.
32
87458691
BRACKET
Bar Clamp
1шт.
Выбрано товаров: 33
