Артикул
Название
Примечание
Количество
1
87405117
SEAT
Seat, Mid-Back - Wheat Color; Incl. 2, 2A; Seat Production P/N 87402555; If Used
1шт.
1
87702543
SEAT
Non-Suspension; See Fig 09-30A
1шт.
2
86603490
SWITCH
Operator Presence; If Used
1шт.
2a
302137A2
HARNESS
Operator Presence Switch Harness With 2 Connectors; Not Illustrated; If Used
1шт.
3
87676122
PLATE
Seat Hinge Plate
1шт.
4
348452A1
FASTENER,Push-In, 37mm L, Nylon
Push In Fastener
5шт.
5
80120101
BOLT
M6 x 30, 8.8 ZND; If Used
2шт.
7
86625263
WASHER,9mm ID x 20mm OD x 1.6mm Thk
4шт.
8
9628098
NUT,M8 x 1.25, Cl 10
If Used
4шт.
8
86629544
NUT,5/16” – 18, GR B
4шт.
9
87676124
FOAM INSULATION
Pad, Seat Noise Control
1шт.
10
348434A1
WASHER,7.14mm ID x 44.5mm OD x 1.3mm Thk
5шт.
11
87676121
STIFFENER
Seat Hinge Stiffener
1шт.
12
254307A1
CLIP
If Used
2шт.
13
189787A2
SHOCK ABSORBER
1шт.
14
86505868
SERRATED NUT,Hex, M8 x 1.25, Cl 8
2шт.
15
189609A1
BALL STUD,M8 x 1.25
Metric Ball Stud, 10mm Ball x M8 X 1.25 Thd
2шт.
16
86508568
BOLT,Hex, M6 x 1 x 16mm, Cl 8.8
4-6шт.
17
87015284
WASHER,8.8mm ID x 21.5mm OD x 2.5mm Thk
8шт.
