/ / / / / / / / (90.160.010) - CAB, REAR COVER
Запчасти Case CX60C (90.160.010) - CAB, REAR COVER (90) - PLATFORM, CAB, BODYWORK AND DECALS
90.120.010
6
8
6
11
15
14
7
4
3
16
12
2
13
6
5
6
9
16
1
10
90.120.020
1
71ML-21051
TRIM
Lower, RH
1шт.
2
71ML-21111
DUCT
1шт.
3
71M9-23341
COVER
1шт.
4
S002-05015B
BOLT
1шт.
5
S035-081526
BOLT,M8 x 1.25 x 15mm
1шт.
6
S002-06015B
SCREW
14шт.
7
S109-080156
BOLT
4шт.
8
71ML-21281
TRIM
Rear, ASSY, Incl 9 - 13
1шт.
9
71ML-21070
TRIM
1шт.
10
NSS
NOT SOLD SEPARAT
Cover, Incl in 8
1шт.
11
71ML-21270
GRILLE
1шт.
12
S002-06015B
SCREW
4шт.
13
S002-05015B
BOLT
8шт.
14
S403-06500B
WASHER
2шт.
15
S403-06100B
WASHER
1шт.
16
S205-06100B
NUT,M8 x 1mm
3шт.
