Запчасти Case CX33C (35.738.020) - DIPPER & BUCKET SECTION, LINES (35) - HYDRAULIC SYSTEMS

1

31MH-50560

STOP

Valve, LH, ASSY, Incl 2 - 8

1шт.

Short Arm (1.3M), Var. 405028, 405032

1шт.

Long Arm (1.6M), Var. 405030, 405034

1шт.

2

31MH-50580

STOP

Valve

1шт.

3

31MH-50600

HYD CONNECTOR

2шт.

4

P030-110003

ELBOW

2шт.

5

P290-100104

PLUG

2шт.

6

S631-018004

O-RING

2шт.

7

S631-024004

O-RING

2шт.

8

S621-014001

O-RING

2шт.

9

35MH-50210CA

PIPE

Bucket

2шт.

10

31MH-50220YLCA

PIPE

1шт.

11

31MH-50230YLCA

PIPE

1шт.

12

35MH-50240CA

PIPE

Breaker

2шт.

13

31MH-50331

HYDRAULIC HOSE

2шт.

Short Arm (1.3M), Var. 405013, 405014

1шт.

13

P914-065023

HYDRAULIC HOSE

2шт.

Long Arm (1.6M), Var. 405017, 405018

1шт.

14

P914-085015

HYDRAULIC HOSE

1шт.

15

P924-085028

HYDRAULIC HOSE

2шт.

Long Arm (1.6M), Var. 405030, 405034

1шт.

15

P924-085020

HYDRAULIC HOSE

2шт.

Short Arm (1.3M), Var. 405028, 405032

1шт.

16

31M6-65100

CLAMP

2шт.

17

31MH-50310

CLAMP

2шт.

18

S581-217000

CLAMP

4шт.

19

35MH-50321CA

COVER

Boom Cylinder

1шт.

20

31M6-65130

COLLAR

4шт.

21

31M6-65140

RUBBER INSULATOR

2шт.

22

31MH-50570

STOP

Valve, RH, ASSY, Incl 3 - 8, 23

1шт.

Short Arm (1.3M), Var. 405028, 405032

1шт.

Long Arm (1.6M), Var. 405030, 405034

1шт.

23

31MH-50590

STOP

Valve

1шт.

24

S621-012001

O-RING

6шт.

25

S621-014001

O-RING

4шт.

26

S035-081556

BOLT

4шт.

27

S109-100406

BOLT

8шт.

Short Arm (1.3M), Var. 405028, 405032

1шт.

Long Arm (1.6M), Var. 405030, 405034

1шт.

28

S037-104526

BOLT,M10 x 1.5 x 45mm

9шт.

28

S037-104526

BOLT,M10 x 1.5 x 45mm

3шт.

Without Quick Coupler, Var. 405040

1шт.

29

S037-105026

BOLT

3шт.

With Quick Coupler, Var. 405037, 405039

1шт.

30

S037-103026

BOLT,M10 x 1.5 x 30mm

2шт.

31

P914-065015

HYDRAULIC HOSE

1шт.

32

S631-014004

O-RING

4шт.

33

S621-012001

O-RING

2шт.
