Запчасти Case CX17C (35.356.040) - PILOT CONTROLS, FOOT CONTROL VALVE, LINES (35) - HYDRAULIC SYSTEMS

1

S631-008004

O-RING

6шт.

2

S631-011004

O-RING,PF 1/4

6шт.

3

S621-011001

O-RING,9/16 - 18 UNF

12шт.

4

32MJ-20050

HYDRAULIC VALVE

EPPR

1шт.

Auxiliary Hydraulic Circuit, With Joystick, Var. 405002, 405005

1шт.

5

X500-110001

HYD CONNECTOR,PF 1/4 x 9/16 - 18 UNF

2шт.

Auxiliary Hydraulic Circuit, With Joystick, Var. 405002, 405005

1шт.

6

X520-110001

ELBOW,PF 1/4 x 9/16 - 18 UNF

4шт.

7

32MJ-40440

ELBOW

1шт.

8

31Q6-20210

HYD CONNECTOR

4шт.

9

S035-082526

BOLT,M8 x 1.25 x 25mm

4шт.

10

S035-086526

BOLT,M8 x 1.25 x 65mm

2шт.

Auxiliary Hydraulic Circuit, With Joystick, Var. 405002, 405005

1шт.

11

X420-042010

HYDRAULIC HOSE,9/16 - 18 UNF x 500mm

1шт.

12

X400-042019

HYDRAULIC HOSE

1шт.

Auxiliary Hydraulic Circuit, With Joystick, Var. 405002, 405005

1шт.

13

X420-042021

HYDRAULIC HOSE

1шт.

14

32MJ-40460

HYD CONNECTOR

1шт.

15

X420-042009

HYDRAULIC HOSE,9/16 - 18 UNF x 450mm

1шт.

Auxiliary Hydraulic Circuit, With Pedal, Var. 405001, 405004

1шт.

16

X420-042026

HYDRAULIC HOSE

1шт.

Auxiliary Hydraulic Circuit, With Joystick, Var. 405002, 405005

1шт.

17

X400-042021

HYDRAULIC HOSE

1шт.
