/ / / / / / / / (90.120.010) - DRIVER SEAT, BASE PLATE
Запчасти Case CX17C (90.120.010) - DRIVER SEAT, BASE PLATE (90) - PLATFORM, CAB, BODYWORK AND DECALS
90.151.030
3
14
17
12
7
10
19
6
11
15
1
5
18
4
16
9
2
13
8
90.151.010
90.151.010
90.151.020
1
72MJ-20100CG
DRIVER SEAT
Base, ASSY, Incl 2 - 17
1шт.
2
72MJ-20120CG
DRIVER SEAT
1шт.
3
72MJ-20110CG
PLATE
1шт.
4
72MJ-22660CG
BRACKET
1шт.
5
71EH-13150
SILENTBLOC
Rubber
1шт.
6
S205-10100B
NUT
1шт.
7
S035-082026
BOLT,M8 x 1.25 x 20mm
4шт.
8
S035-061526
BOLT
2шт.
9
75Q4-21030
GROMMET
RH
1шт.
10
72MJ-22830
INSULATION
1шт.
11
72MJ-22840
INSULATION
1шт.
12
72MJ-22850
INSULATION
1шт.
13
72MJ-22860
INSULATION
1шт.
14
72MJ-22870
INSULATION
1шт.
15
S773-020000
WEATHERSTRIP
1шт.
16
72MJ-22920
INSULATION
1шт.
17
72MJ-22930
INSULATION
1шт.
18
S035-082526
BOLT,M8 x 1.25 x 25mm
8шт.
19
S037-102526
BOLT,M10 x 1.5 x 25mm
2шт.
