Запчасти Case CX55B (35.310.AA[18]) - SELECTOR, VALVE, ASSY (BHL MULTI) (35) - HYDRAULIC SYSTEMS

1

PY30V00065F1

VALVE

Selector, BHL Multi, Incl 2 - 14

1шт.

2

PY30V00065S002

SHAFT

1шт.

3

YN30V00115S006

WASHER

1шт.

4

PY30V00065S004

HOUSING

1шт.

5

PY30V00065S005

LEVER

1шт.

6

PY30V00065S006

WASHER

1шт.

7

YN30V00115S008

SCREW

Cap

2шт.

8

YN30V00115S009

BOLT

1шт.

9

YN30V00080S023

SCREW

2шт.

10

YN30V00115S011

PIN

Spring

3шт.

11

PY30V00065S012

RING

1шт.

12

YN30V00115S013

SEAL

Dust

1шт.

13

ZD11P02600

O-RING

1шт.

14

YN30V00115S015

O-RING

1шт.
