Запчасти Case CX36B (01-004) - COUNTERWEIGHT INSTAL (05) - SUPERSTRUCTURE

PX60C00017F1

COUNTERWEIGHT INSTALLATION

1шт.

a1

PX60C00014P1

COUNTERWEIGHT

1шт.

PW60C00018F1

ASSY

1шт.

b1

PW60C01019P1

RUBBER

2шт.

b2

PW60C01020P1

FOAM INSULATION

1шт.

b3

PW60C01024P1

FOAM INSULATION

1шт.

b4

PW60C01026P1

FOAM INSULATION

1шт.

b5

PW60C01023P1

FOAM INSULATION

1шт.

b6

PW60C01027P1

FOAM INSULATION

1шт.

b7

PW60C01028P1

FOAM INSULATION

1шт.

PW60C00019F1

INSTAL

1шт.

c1

HS18C20090G1

BOLT

CAP

1шт.

c2

HS18C20065G1

BOLT

CAP

2шт.

c3

HY26Y21050G4

WASHER

3шт.

c4

PM60C01022D1

SHIM

(1.0)

3шт.

c5

PM60C01022D2

SHIM,2.0mm Thk

3шт.

c6

PM60C01022D3

SHIM

(3.2)

3шт.

c7

YT60C01007P1

PLUG

2шт.

c8

LE60C01028P1

PLATE

2шт.
